Research in Optical Image Differential Based on Digital Filter

Abstract:

In this paper, we create the optical differential filter displayed on a digital micromirror device which achieving differential operation of image is proposed. We produced the digital cosine composite grating through the computer which replaced the traditional holographic composite grating filter, and transmitted the image of composite grating to the DMD which connected to the computer. This method can produce optical filters quickly, avoiding developing, fusing processing, and can according to the specific requirements of the image to adjust the filter quickly. The method not only can save time, but also can improve the processing accuracy greatly.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 4466-4469
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.4466
• Online since: February 2014
• Authors: Huan Dong*
• Keywords: Composite Grating, Digital Micromirror Device, Image Differential, Optical Information Processing

References

[1] Huan Dong, The measurement of 3D object shape based on Fourier Transform Profilometry, Advanced Materials Research, Vol. 678, pp.756-759(2013).

DOI: 10.4028/www.scientific.net/amr.756-759.678

[2] Naiguang Lv, Fourier optics [D], China Machine Press Pub(2006).

[3] Haohan Xu, Image differentiation by grating encoding[J], Physics Experimentation, Vol. 28, No. 10, pp.26-27(2008).

[4] Honghui Sun, Suxia Hou, Qinghua Zhang, The diferential coefficient process and correlation recognition of images[J], Optical Technique, Vol. 33, No. z1, pp.73-78(2007).

[5] Chengtai Xue, Andreaslie Knut, TonyF. Chan et. al, Image processing based on partial differential equations[D], Springer(2006).

[6] Luc M. J. Florack, Bat M. ter Haar Romeny, Jan J. Koenderink et. al, Scale and the differential structure of images[J], Image And Vision Computing, Vol. 10, pp.376-388(1992).

DOI: 10.1016/0262-8856(92)90024-w

[7] M.G. Taylor, Phase estimation methods for optic coherent detection using digital signal processing[J], Light-Wave Technol, Vol. 27, No. 7, pp.901-914(2009).

DOI: 10.1109/jlt.2008.927778

[8] Shuqun Zhang, Mohammad A Karim, Normalized joint transform correlation for target recognition[J], Vol. 5(2000).

[9] Junhong Su, Aiming Ge, Enhanced optical image edge with laster speckle out-of-focus method[J], Optical Instruments, Vol. 23, No. 2(2001).

[10] Wang Z Q, Soutar C., Gillespie W. A. et. al, Real-time edge-enhanced object correlation using incoherent readout of photorefractive BSO[J], Optik, Vol. 4, pp.157-162(1993).

[11] A.W. Lohman, D.P. Paris, Computer generated spatial filters for coherent optical data processing[J], Vol. 7, pp.651-655(1968).

[12] Leonid B. Glebov, Julien Lumeau, Sergiy Mokhov et. al, Reflection of light by composite volume holograms: Fresnel corrections and Fabry=Perot spectral filtering[J], JOSA A, Vol. 25(2008), pp.751-764.

DOI: 10.1364/josaa.25.000751

[13] Junfa He, Hongxia Wang, Jun Wang, Application of composite grating filter in optical image recognition system[J], Journal Of Shaanxi Normal University, Vol. 32, No. 2(2004).

[14] Haitao Zhang, Mali Gong, Dazun Zhao, Anti-aliasing 4f filtering systems[J], Optical Technology, Vol. 27, No. 1(2011).

[15] Ziyun Zhang, The study of holographic display system based on DMD[D], Anhui University(2006).
