Effect of Stand-Off Distance on Impact Pressure of High-Speed Water Jet Injected in Water

Abstract:

This study is to measure the impact pressure of high-speed water jet injected in water at the stand-off distance from the nozzle exit. The high-speed water jets are generated by the impact of a projectile, which known as impact acceleration method, launched by Horizontal Single Stage Power Gun. The maximum averaged jet velocity of about 374.24 m/s in water was generated in this experiment. The impact pressure of high-speed water jet in water at the stand-off distance 15, 20, 30 and 40 mm from the nozzle exit was measured by the PVDF pressure sensor. Moreover, the impact phenomena of the jet were visualized by a high-speed video camera with shadowgraph optical arrangement. From the pressure sensor, two peak over-pressures are always observed in this experiment. From visualization, it was found that the two peak over-pressures of 24 GPa and 35 GPa at x = 15 mm were generated by the jet and the bubble impact, respectively. The peak over-pressure decreases exponentially as the stand-off distance between the PVDF pressure sensor to the nozzle exit increases. Moreover, the jet and the bubble impact on the PVDF pressure sensor, shock waves, and bubble deformation were obviously observed in this study.

• Periodical: Applied Mechanics and Materials (Volumes 52-54)
• Pages: 1873-1878
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.52-54.1873
• Online since: March 2011
• Authors: Anirut Matthujak, Chaidet Kasamnimitporn, Wuttichai Sittiwong, Kulachate Pianthong
• Keywords: High-Speed Submerged Water Jet, Impact Acceleration Method, Impact Pressure, PVDF Pressure Sensor, Shadowgraph

References

[1] M.C. Rochester, and J.H. Brunton: High-speed impact of liquid jets on solid, 1st International Symposium on Jet Cutting Technology, Coventry, UK. (1972) paper A1.

[2] B.E. Edney: Experimental studies of pulsed water jets, 3rd International Symposium on Jet Cutting Technology, Chicago, USA (1976) paper B2.

[3] K. Pianthong, A. Matthujak, and K. Takayama: Dynamic characteristics of pulsed supersonic fuel sprays, Shock Waves, Vol. 18 (2008) pp.1-10.

DOI: 10.1007/s00193-008-0123-4

[4] H. H. Shi, and K. Takayama: Generation of hypersonic liquid fuel jets accompanying self-combustion, Shock Waves, Vol. 9 (1999) pp.327-32.

DOI: 10.1007/s001930050193

[5] T. Ohki, A. Nakagawa, T. Tominaga, and K. Takayama: Experimental application of Pulsed Ho: YAG laser-induced liquid jet as a novel device for rigid neuroendoscope, Laser Surg Med, Vol. 34 (2004) p.227.

DOI: 10.1002/lsm.20021

[6] A. Nakagawa, T. Hirano, M. Komatsu, M. Sato, H., Uenohara, H. Ohgawa, Y. Kusada, R. Shirane, K. Takayama and T. Yoshimoto: Holmium YAG laser-induced liquid jet knife: possible novel method for dissection, Lasers Surg Med, Vol. 31 (2002) p.125.

DOI: 10.1002/lsm.10055

[7] M. Iwasaki: Application of Water jet for Drilling Rocks Undersea, Turbomachinery, Vol. 17(12) (1989). P. 761-767.

[8] H. Soyama, Y. Yanauchi, K. Sato, T. Ikohagi, R. Oba, and R. Oshima: High-speed observation of ultrahigh-speed submerged water jets, Experimental Thermal and Fluid Science, Vol. 12 (1996) pp.411-416.

DOI: 10.1016/0894-1777(95)00124-7

[9] K. Ohtani, D. Numata, K. Takayama, T. Kobayashi, and K. Okatsu: Experimental study of underwater rock drilling using a pulsed Ho : YAG laser-indued jets, Shock wave, Vol. 19 (2009) pp.403-412.

DOI: 10.1007/s00193-009-0221-y

[10] F.P. Bowden, and J.H. Brunton: Damage to solids by liquid impact at supersonics speeds, Nature, Vol. 181 (1958) pp.873-875.

DOI: 10.1038/181873a0

[11] J.D. O'Keefe, W.W. Wrinkle, and C.N. Scully: Supersonic liquid jets, Nature, Vol. 213 (1967) pp.23-25.

DOI: 10.1038/213023a0

[12] W. Sittiwong, W. Seehanam, K. Pianthong, and A. Matthujak: Effect of stand-off distance on impact pressure of high-speed water jets, The 10th Asian International Conference on Fluid Machinery, Kuala Lumpur Malaysia, (2009) paper no. 171.

DOI: 10.1063/1.3464938
