Realization of Atomizing Animation for Spraying Based on OpenGL in the Electrostatic Oiler

Abstract:

For principle of the particle system, using Visual C++ combining with the object-oriented technology and open graphic library method, the shapes of oil atomization under different voltages were simulated. By comparing the simulating images with the experimental pictures, charged oil atomization process was basically reflected by the simulated results, and it was correspondent with the experimental observation.
