Lightweight Study on Axial Crushing Thin Cylindrical Tubes of Steel and Aluminum Alloy Based on Equal Energy Absorption

Abstract:

A thin cylindrical tube model was established. Its energy absorption property was analyzed when crushing through finite element method. Then its validity was verified through the corresponding experiment. On the basis of the above research, two different material tubes were selected which were aluminum alloy 6060 and cold-roll steel B340LA. Considering the mechanical performance of these two materials might change during dynamic crushing, so the tubes were crushed in three modes including low speed, medium speed and high speed. In order to predict the wall thickness of the two different material tubes when their energy absorption was equal, two methods were proposed which were overall energy method and the stress-strain energy method. Then get the mass ratio of the two different material tubes when they absorbed equal energy. The results showed that the mass of aluminum alloy 6060 tube was about 86%-90% to B340LA tube when they absorbed equal energy. More than 10% lightweight effect could be obtained when cold-roll steel B340LA tube was instead with aluminum alloy 6060 under the condition of their absorbing equal energy.

• Periodical: Applied Mechanics and Materials (Volume 525)
• Pages: 117-122
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.525.117
• Online since: February 2014
• Authors: Chuan Qing Wang, Deng Feng Wang*, Wei Min Zhuang, Ming Xin Zhang
• Keywords: Axial Crushing, Equal Energy Absorption, Material Substitution, Thin Cylindrical Tubes

References

[1] Abramowicz W. The effective crushing distance in axially compressed thinwalled metal columns. Impact Engineering. VOL. 1(1983),P. 309–317.

DOI: 10.1016/0734-743x(83)90025-8

[2] Jones N, Abramowicz W. Static and dynamic axial crushing of circular andsquare tubes. Metal Forming and Impact Mechanics. VOL. 2(1985),P. 225–247.

DOI: 10.1016/b978-0-08-031679-6.50021-7

[3] Wierzbicki T, Bhat SC, Abramowicz W. Alexander revisited a two foldingelements model for progressive crushing of tubes. Solids and Structures. VOL. 29(1992),P. 3269–3288.

DOI: 10.1016/0020-7683(92)90040-z

[4] Karagiozova D, Jones N. Dynamic effects on buckling and energy absorptionof cylindrical shells under axial impact. Thin-Walled Structures. VOL. 39(2001),P. 583–610.

DOI: 10.1016/s0263-8231(01)00015-5

[5] Galib DA, Limam A. Experimental and numerical investigation of static anddynamic axial crushing of circular aluminum tubes. Thin-Walled Structures. VOL. 42(2004),P. 1103–1137.

DOI: 10.1016/j.tws.2004.03.001

[6] HongmeiPeng，Ping Hu，GuozheShen. The finite element simulation and analysis for the crash performance of an automotive thin walled column. Wuhu: The 8th Int. Forum of Automotive Traffic Safety (INFATS), (2010).

[7] Abramowicz W, Jones N. Dynamic axial crushing of circular tubes. Impact Engineering. VOL. 2(1984),P. 263–81.

DOI: 10.1016/0734-743x(84)90010-1

[8] Lorenzo Peroni, MassimilianoAvalle, Marco Peroni. The mechanical behaviour of aluminium foam structures in different loading conditions. ImpactEngineering. VOL. 35(2008),P. 644-658.

DOI: 10.1016/j.ijimpeng.2007.02.007
