Research on Characteristics of the Photovoltaic Cells Integrated on Chip

Abstract:

The influence factors of Photovoltaic (PV) cells characteristics integrated on chip were analyzed based on the fabrication process and the structure of the PV cells and CMOS devices. The results show the substrate doping concentration, the emitter doping concentration, the emitter junction depth and the thickness of device layer directly determine the conversion efficiency, open voltage and the light-generated current of photovoltaic cells. In the emitter doping concentration range of 1×10¹⁹/cm³ to 1×10²¹/cm³ and the substrate doping concentration range of 1.0×10¹⁵/cm³ to 1.0×10¹⁷/cm³, the Photovoltaic cells have batter conversion characteristics. The PV cells were designed based on the analysis results in PC1D, and the conversion efficiency is 9.43%. The Photovoltaic cells and the CMOS devices have batter fabrication technology compatibility integrated on chip.

• Periodical: Applied Mechanics and Materials (Volume 525)
• Pages: 287-291
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.525.287
• Online since: February 2014
• Authors: Li Xian Xiao, Yong Tai He*, Yue Hong Peng, Jin Hao Liu
• Keywords: Integrated on Chip, Micro Power Supply, Photovoltaic Cells

References

[1] P. Chulsung., Challenges on the Design and Evaluation of Wireless Sensor Platform for Real-World Application. United States: University of Carolina libraries, (2007).

[2] P.B. Koeneman., I.J.B. Vishniac., K.L. Wood., Feasibility of micro power supplies for MEMS. Microelectromechanical Systems. 6(1997)355-362.

DOI: 10.1109/84.650133

[3] M.P. Buric., G. Kusic., W. Clark., T. Johnson., Piezo-Electric Energy Harvesting for Wireless Sensor Networks. Wireless and Microwave Technology Conference. (2006) 1-5.

DOI: 10.1109/wamicon.2006.351939

[4] O. Jun., K. Masanori., T. Tatsuhiko., A GaAs Micro PV cells with Output Voltage over 20 V. Japanese Journal of Applied Physics. 38 (1999) 6947-51.

[5] J. B. Lee.,.Z. Chen., M. G. Allen., A. Rohatgi., A high voltage PV cells array as an electrostatic MEMS power supply. IEEE Proceedings in Micro Electro Mechanical Systems(1994): 331 -336.

DOI: 10.1109/memsys.1994.555833

[6] M. Daniel., R. H. Bennett., A control circuit for a microsensor hybrid power supply. IEEE transactions on industrial electronics. 51 (2004) 74-80.

DOI: 10.1109/tie.2003.822087

[7] Q . ZH. Men., H. B . Liu., Q. H. Men., Semiconductor physics, Science Press, Beijing, January (2005).

[8] F. Robert., Semiconductor devices based on, Electronics Industry Press, Beijing, November (2004).
