Sampling Strategy for Free-Form Surface Inspection Using Coordinate Measuring Machines

Abstract:

Due to the complexity and non-rotational symmetry of free-form surface, it is difficult to achieve accurate and efficient inspection method. In order to solve this problem, three types of sampling sequences are proposed to specify a set of measuring points of free-form surface. For comparing the results of different sampling strategies, the profile errors of free-form surface are calculated based on a quasi particle swarm optimization (QPSO) searching the transformation parameters to implement localization and surface subdivision method finding the closest points on the design model corresponding to measured points. In order to obtain effective sampling strategies, four design models are generated by non-uniform rational basis spline (NURBS) and parts are manufactured on two machining centers to obtain surfaces of different roughness and measured on CMMs by selecting different sampling methods and sample sizes. The profile errors of parts are calculated by the proposed method and CMMs software, respectively. The results show that randomized Hammersley sampling sequence and medium sample size are preferred for the profile error inspection of given parts if accuracy and time are all considered. The research provides a method for free-form surface accurate inspection while minimizing the sampling time and cost.

• Periodical: Applied Mechanics and Materials (Volume 532)
• Pages: 106-112
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.532.106
• Online since: February 2014
• Authors: Xiu Lan Wen*, Dong Xia Wang, Li Fang, Yi Bing Zhao
• Keywords: Free-Form Surface Inspection, Randomized Hamersley Sampling, Sampling Strategy

References

[1] J. Wang, X.C. Wang and H. Jiang, Coordinate measurement of tooth surface of spiral bevel gear, Journal of Mechanical Engineering, 39(2003) 151-154 (Chinese).

DOI: 10.3901/jme.2003.06.151

[2] X.L. Wen, J.C. Huang, D.H. Sheng, et. al, Flatness error evaluation and verification based on new generation geometrical product specification (GPS), Precision Engineering, 34(2010) 338-344.

DOI: 10.1016/j.precisioneng.2011.07.006

[3] H. Ramaswami, S.B. Acharya, Y. Kovvur, et. al, A multivariate statistical analysis of sampling uncertainties in geometric and dimensional errors for circular features, Journal of Manufacture Systems, 25(2006) 78-93.

DOI: 10.1016/s0278-6125(07)00005-2

[4] R.J. Hocken, J. Raja and U. Babu, Sampling issues in coordinate metrology, Manufacturing Review, 6 (1993) 282-294.

[5] G. Lee, J. Mou and Y. Shen, Sampling strategy design for dimensional measurement of geometric features using coordinate measuring machine, International Journal of Machine Tools & Manufacture, 37(1997) 917-934.

DOI: 10.1016/s0890-6955(96)00096-x

[6] W.S. Kim and S. Raman, On the selection of flatness measurement points in coordinate measuring machine inspection, International Journal of Machine Tool & Manufacture, 40(2000) 427-443.

DOI: 10.1016/s0890-6955(99)00059-0

[7] R. Raghunandan and P.V. Rao, Selection of sampling points for accurate evaluation of flatness error using coordinate measuring machine, Journal of Materials Processing Technology, 202 (2008) 240-245.

DOI: 10.1016/j.jmatprotec.2007.09.066

[8] B.M. Colosimo, M.E. Gutierrez, G. Moroni, et. al, A tolerance interval based criterion for optimizing discrete point sampling strategies, Precision Engineering, 34 (2010) 745-754.

DOI: 10.1016/j.precisioneng.2010.04.004

[9] X.C. Wang and Y. Yu, An approach to interference-free cutter position for five-axis free-form surface side finishing milling, Journal of Materials Processing Technology, 123(2002) 191-196.

DOI: 10.1016/s0924-0136(02)00023-7

[10] M.Y. Chen and Y.H. Liu, Research on sampling strategy for free-form surfaces based on shape features, Machinery Design & Manufacture, 3(2011) 190-192, 2011 (Chinese).

[11] Y. Li and P.H. Gu, Automatic localization and comparison for free-form surface inspection, Journal of Manufacturing Systems, 25(2006) 251-268.

DOI: 10.1016/s0278-6125(08)00007-1

[12] S. Balasubramanian and P. Gu, A neural network approach to localization of parts with complex surfaces for precision inspection, Proc. 1995 ASME Computers in Engineering Conference, Boston, America, September 17–20 (1992) 1025-1031.

DOI: 10.1115/cie1995-0834

[13] X.L. Wen, Y.B. Zhao, D.X. Wang, et. al, Accurate evaluation of f free-form surface profile error based on quasi particle swarm optimization Algorithm and surface subdivision, Chinese Journal of Mechanical Engineering, 26 (2013) 406-413.

DOI: 10.3901/cjme.2013.02.406

[14] R.J. Campell and P.J. Flynn, A survey of free-form object representation and recognition techniques, Computer Vision and Image Understanding, 81(2001) 166-210.

DOI: 10.1006/cviu.2000.0889

[15] P. Balakrishna and S. Raman, An integrated approach for the estimation of spherical form tolerance, Journal of Manufacturing Systems, 25(2006)172-183.

DOI: 10.1016/s0278-6125(08)00004-6

[16] P.R. Krishnaiah, Sampling(Second Edition), New York : North-Holland, (1988).

[17] Y.F. Zhang, A.Y.C. Nee, J.Y.H. Fuh, et. al, A neutral network approach to determining optimal inspection sampling size for CMM, Computer Integrated Manufacturing Systems, 9 (1996) 161-169.

DOI: 10.1016/s0951-5240(96)00005-5

[18] C.F. Cheung, H.F. Li, L.B. Kong, et al, Measuring ultra-precision freeform surfaces using a robust form characterization method, Measurement Science and Technology, 17(2006) 488-494.

DOI: 10.1088/0957-0233/17/3/s05
