The Design of Indexable Gear Insert and Cutting Parameter Optimization

Abstract:

The gear is widely used in manufacturing industry. The object of study is straight spur gear. According to the feature of involute gear, a three-edged indexable milling insert is designed. Firstly, the milling model is built in Deform3D. Then, the optimal relief angle is gained based on the cutting temperature and the optimal relief angle is 6°. The cutting parameters are researched and the optimal parameters are obtained according to the cutting force.

• Periodical: Applied Mechanics and Materials (Volume 532)
• Pages: 540-544
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.532.540
• Online since: February 2014
• Authors: Jian Chen, Hong Mo Shang, Liang Tian, Gui Cheng Wang*
• Keywords: Cutting Parameter Optimization, Indexable Gear Insert, Involute Gear, Relief Angle

References

[1] X.C. Liang, M. Shao The Research on Manufacturing of Gear and tool, Chongqing University press, Chongqing, (2001).

[2] Y.Q. Peng, The Design of Plate Type Indexable Gear Milling Cutter, Journal of Tool Engeering. 8(2012) 68-70.

[3] Mechanical design editorial board, Handbook of Mechanical Design, China Machine Press, Beijing, (2004).

[4] X.T. Wu, The Principle of Gear Meshing, Second edition, Xi'an Jiaotong University Press, Xi'an, (2009).

[5] L.L. Xia, J.T. Yuan, Simulation and Test Research of Milling Force Based on Software Deform-3D, Machinery Design ＆ Manufacture, 4(2013)85-87.
