Study of Influence Effect on Heat Transfer Performance of Single-Loop Oscillating Heat Pipe

Abstract:

s. The experiment studied the effect of heat source temperature, heating section length ratio, cooling air flow rate, liquid filling rate and pipe diameter on the heat transfer performance of the single-loop red copper-water oscillating heat pipe. The results show that increasing heat source temperature or pipe diameter and reducing filling rate can obviously reduce the thermal resistance of the heat pipe; in the air cooling mode, the cooling thermal resistance outside the pipe is affected by both cooling conditions and heat pipe cooling section average temperature; when the heating section is shorter than the cooling section, the heat pipe thermal resistance shows an apparent trend of increasing with the increase of heating section length ratio, when the heating section is longer than the cooling section, the cooling thermal resistance increases with it apparently; the heat transfer power is the highest when the filling rate is 50%.

• Periodical: Applied Mechanics and Materials (Volume 535)
• Pages: 114-118
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.535.114
• Online since: February 2014
• Authors: Su Lei*
• Keywords: Experimental Research, Heat Transfer Performance, Single Loop Oscillating Heat Pipe, Theoretical Model

References

[1] H. Akachi, Structure of a Micro Heat Pipe[P]. US 5219020, (1993).

[2] H.H. Yang , S. Khandekar, M. Groll, Performance characteristics of pulsating heatpipes as integral thermal spreaders, Therm. Sci., 48 (4) (2009) 815-824.

DOI: 10.1016/j.ijthermalsci.2008.05.017

[3] H.H. Yang, S. Khandekar, M. Groll, Experimental Investigation of the Flow Patterns in a Single Closed Loop Pulsating Heat Pipe, Fluid Mach., 35 (1) (2007) 60-63.

[4] L.H. Fu, Experimental Research on Heat Transfer performance of Pulsating Heat Pipe, REFRIGERATION, 7(2)(2008)7-11.

[5] J.T. Li , Z.X. Han, Z.H. Li , et al. An Analysis of Flow Patterns and Directions of a Pulsating Heat Pipe, J. Eng. Therm. Energy Power, 24(3)(2009)347-351.

[6] H.H. Yang, C. Zhang, M. Groll, Comparion between Two K inds ofPulsating HeatPipes (C ircle Tube Type and FlatPlate Type w ith Square Channels), Fluid Mach., 37(6) (2009)70-72.

[7] H.H. Yang, S. Khandekar, M. Groll, Operational limit of closed loop pulsating heat pipes, Appl. Therm. Eng., 28(2008)49–59.

DOI: 10.1016/j.applthermaleng.2007.01.033

[8] S. Lips, A. Bensalem, Y. Bertin, A. Vincent, C. Romestant, J. Bonjour, Experimental evidences of distinct heat transfer regimes in pulsating heat pipes (PHP), Appl. Therm. Eng., (2010)951-957.

DOI: 10.1016/j.applthermaleng.2009.12.020

[9] S. f. Wang, S.F. Nishio, Effect of Length Ratio of Heating Section to Cooling Section on Properties of Oscillating Heat Pipes, J. S. China Univ. Technol. (Nat. Sci. Edit. ), 35(11)(2007) 59-61.

[10] W. Qu, T.Z. Ma, Steady state operational mechanism of looped pulsating heat pipe, J. Eng. Therm., 25(2)(2004)323-325.

[11] D.Z. Yuan, W. Qu, T.Z. Ma, Flow and heat transfer of liquid plug and neighboring vapor slugs in a pulsating heat pipe, Int. J. Heat Mass Transf., 53(6) (2010)1260–1268.

DOI: 10.1016/j.ijheatmasstransfer.2009.12.042

[12] S.F. Wang, S. Nishio, Study on heat transport characteristic of closed loop SEMOS heat pipe/ASME Summer Heat Transfer Conference, July17-22, San Francisco, USA, (2005).

[13] S.F. Wang, S. Nishio，Heat transfer performance of a closed oscillating heat pipe/IHTC-13 August13-18, Sydeny, Australia, (2006).

DOI: 10.1615/ihtc13.p22.380
