Cutter Contacting Machining Paths Generation Method for Surface Flat-End Milling

Abstract:

In order to enhance machining precision of complex surfaces with a flat-end cutter, the generating method of cutter contacting (CC) paths is presented in this article. With the method of coordinate transformation, effective machining radius of a flat-end cutter had been deduced and the step-over formed by two adjacent CC paths were implemented. The parameter increment along the CC path interval direction was calculated by using geometric analysis of the local area of CC point. The corresponding NURBS path of tool center points including knot vector and controlling points was obtained from the cutter contacting points.

• Periodical: Applied Mechanics and Materials (Volumes 536-537)
• Pages: 1630-1633
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.536-537.1630
• Online since: April 2014
• Authors: Hui Ying Li, Liang Ji Chen*
• Keywords: Complex Surface, Cutter Contacting Point, Flat-End Milling, Machining Path

References

[1] M. Tikhon : International Journal of Machine Tools & Manufacture Vol. 44 (2004), p.237.

[2] M. Y. Cheng, M. C. Tsai and J. C. Kuo: International Journal of Machine Tools & Manufacture Vol. 42(2002), p.801.

[3] M. C. Tsai, C. W. Cheng and M. Y. Cheng: International Journal of Machine Tools & Manufacture Vol. 43(2003), p.1217.

[4] R. S. Lin: International Journal of Machine Tools & Manufacture Vol. 43(2000), p.1513.

[5] L. Piegl: IEEE Computer Graphics & Application Vol. 11(1991), p.55.
