Study of Heat Losses from Cylindrical Cavity Receiver of Solar Concentrator

Abstract:

In this paper heat losses from cavity receiver of solar concentrators are presented. Convective and radiative losses for specified cavity receiver are estimated by MATLAB programming and effect of the various parameters is studied. Radiation losses are analyzed for operating temperature in range of 127°C to 527 °C and aspect ratio of 0.5 to 2.5. Convective losses are investigated for operating temperature in range of 127°C to 527 °C, inclination angle from 0 to 90^o, aspect ratio of 0.5 to 2.5 and wind effect for 0 to 10 m/s. Radiation losses and convective losses increases as operating temperature of cavity receiver increases. The convective losses are more for sidewise facing cavity (0^o inclination) and less for downward facing cavity (90^o inclination). As aspect ratio and wind velocity increases, convective loss increases.

• Periodical: Applied Mechanics and Materials (Volumes 541-542)
• Pages: 996-1001
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.541-542.996
• Online since: March 2014
• Authors: Sanjay D. Barahate, P.R. Dongarwar, Vinod C. Shewale
• Keywords: Cavity Receiver, Convection Loss, Wind Effect

References

[1] Clausing, A. M , Wagner, K.C. and Skarda, R.J., An Experimental Investigation of Combined Convection from a Short Vertical Cylinder in a Crossflow, Journal of Heat Transfer, Vol. 106, pp.558-562, August 1984. (Journal paper).

DOI: 10.1115/1.3246715

[2] Harris, J.A. and Lenz, T.G., Thermal Performance of Solar Concentrator/Cavity Receiver Systems, Solar Energy, Vol. 34, No. 2, pp.135-142, 1985. (Journal paper).

DOI: 10.1016/0038-092x(85)90170-7

[3] Stine, W.B. and McDonald, C.G., Cavity Receiver Convective Heat Loss: Proc. International Solar Energy Society Solar World Congress, Kobe, Japan, Vol. 2, pp.1318-1322, (1989).

[4] Kedare S. B. (2006), Solar concentrators for industrial process heat, Procedings of International congress on Renewable Energy, pp.135-141.

[5] Barahate S. D., Prakash M. and Kedare S. B. (2009), Experimental Thermal Analysis of a Solar Cavity Receiver, International Energy Journal, RERIC, pp.

[6] Barahate S. D., Prakash M. and Kedare S. B. (2004), Heat loss analysis of cavity receivers for solar concentrators, International Mechanical Engineering Conference and Expo 2004, Kuwait City, Kuwait pp.136-152.

[7] Koenig A. A. and Marvin M. (1981), Convection heat loss sensitivity in open cavity solar Receivers, Final report, DOE contract No EG77-C-04-3985, Department of energy, Oak Ridge, Tennessee.
