Research on Yinma Palletizing Robot Motion Feasibility Based on MATLAB-Robotics Toolbox

Abstract:

To realize the working requirements of silver Horse Companys palletizing robot. Firstly, MATLAB software was used to establish mathematical model of the robot, and it calculated the robot workspace and generated workspace figures; it can also verify whether the predetermined grip and place points satisfy a predetermined workspace. Based on this analysis inverse kinematic of the robot, each joint angle from gripping position to place position was calculated. Polynomial interpolation method is applied to calculate the each joint trajectory; Finally, Robotics Toolbox is used to simulate the robot kinematics, and get the trajectory of the robot terminate executive body; each joint position, velocity trajectory can ensure no sudden change occurs in joint angular. In this paper, robot inverse kinematics completed robot end actuator position and posture transformation from the Cartesian space to the joint space. In order to make the joint space path planning possible, this will greatly simplify the calculation. And the joint space and Cartesian coordinate space does not exist a continuous relation, thus eliminating the singularity problem.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 1296-1300
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.1296
• Online since: March 2014
• Authors: Wei Xu*, Si Cong Yuan, Ying Hui Cao
• Keywords: Inverse Kinematic, Palletizing Robot, Polynomial Interpolation Method, Robot Workspace, Simulation Robot Kinematics

References

[1] John J. Craig. Introduction to robotics[M]. Beijing: Mechanical industry press, (2005).

[2] LiJin-Quan, YangXiang-Dong, FuTie. Palletizingrobot[M]. Beijing: Beijing university of science and technology press, (2011).

[3] Zhao Yan-jiang, Zhang Yong-de, Shao Jun-peng. A Method for Solving Robot Workspace Based on Matlab[J]. Mechanical Science and Technology for Aerospace Engineering, 2009, 12(28): 1659 -1665.

[4] Cai Zi-Xing. robotics [M]. Beijing: QingHua university press, (2000).

[5] Yu Tian-yu, Li-da, Song Bao-yu . Research on Trajectory Planning and Simulation of Industrial Robots Based on MATLAB-Robotics Toolbox[J]. MANUFACTURING INFORMATIZATION, 2011, (7): 85- 89.

[6] Piao M B, et al. Research on workspace of a two-arm surgical robot[A]. Proceedings of the 2007 IEEE International Conference on Mechatronics and Automation[C], (2007).

DOI: 10.1109/icma.2007.4303696
