Research on the Parameter Conversion of Mannequin Curve

Abstract:

In order to realize the reverse design of human bodys curve, the curves parameter conversion and reconstruction based on non-contact measuring system are studied in the paper. Firstly, obtain the model of point cloud data by the non-contact measurement system, and then import the data into reverse the engineering software Geomagic. Second, process the point cloud data with the method of human characteristic curves and surfaces division, structure fitting surface, and get the three-dimensional reconstruction model of human bodys point cloud data. Lastly, import the model into the forward design software Solidworks with different methods and edit it. Then finish the parameter conversion from Geomagic to the forward design software. The reconstruction method has a good value in reverse design of the mold.

• Periodical: Applied Mechanics and Materials (Volumes 543-547)
• Pages: 2656-2659
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.543-547.2656
• Online since: March 2014
• Authors: Bo Ren*, Ji Xin Yang, Peng Wan, Xue Heng Tao, Xue Jun Wang, Hui Hui Wang
• Keywords: Curve, Geomagic, Parameter Transformation, Reverse Engineering, SolidWorks
