MCU Control Technology of 3D Image Processing Based on Photoelectric Coupler

Abstract:

In the micro display device, we can achieve the binocular 3D imaging, to carry on wireless sensor control and the implementation of naked eye 3D image expression effect. The application of controllable silicon type photoelectric coupler MOC3041 and CD4069 phase inverter design the control circuit of image capture clock, and then the use of MCU control algorithm designs the wireless sensor signal acquisition PC circuit. Finally, this paper uses a liquid crystal screen, polarizing film and polymer liquid crystal layer to carry on 3D image synthesis experiment, we can obtain the very good 3D image expression effect, and the technology will be extended to the basketball training process, to receive the application of computer 3D imaging technology.
