The Bionic Optimization and Analysis and Calculation of the Cast-Steel Joint with Three Branches

Abstract:

The tree-like structure is a branch of space bionic structures,belonging to the Bionic Architectural Structures. Cast-steel joints with branches are the keys to build the tree-like structures.They are used widely,and the most common joints in our projects are cast-steel joints with two、three and four branches. The cast-steel joints with two branches are planar,while the joints with three and four branches are spatial.Until now,the basic theoretical researches about the cast-steel joints with branches are also relatively scarce.This paper did researches about mechanical properties, calculation methods and structural optimization of the cast-steel joints with three branches deeply and systematically. The result shows that the bending moment has a big influence on the value of the max stress. And the three main failure modes of the cast-steel joint with three branches are yield of the main tubular along the axial direction, local buckling at the connection of the main tubular and branches, and the tearing out of the branches.

• Periodical: Applied Mechanics and Materials (Volumes 548-549)
• Pages: 1618-1622
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.548-549.1618
• Online since: April 2014
• Authors: Zheng Hao Zhu, Wen Feng Du, Zhi Fei Sun, Li Ming Zhu
• Keywords: Cast-Steel Joint with Three Branches, Finite Element Method (FEM), Tree-Like Structures

References

[1] DONG Shilin. Development and expectation of spatial structures in China[J]. Journal of Building Structures, 2010, 31(6): 38-51. (in Chinese).

[2] H. schober. Cast steel joints for tubular structures[A]. Tubuler structure X[C]. Mardred: Ballkema, 2003: 143-152.

[3] Herion, S. Castings in tubular structures - the state of the art[A]. Proceedings of Institution of Civil Engineering-Structures and Buildings[C], 2010, 163(6): 403-415.

DOI: 10.1680/stbu.2010.163.6.403

[4] LIU Zhao, HE Zhiqi, SU Jian. Application and study of cast steel joints to light bridges [J]. World Bridges, 2011, 19(5): 31-34. (in Chinese).

[5] Zhao X. L., Tong L. W. New Development in Steel Tubular Joints[J]. Advances in Structural Engineering, 2011, 14(4): 699-715.

DOI: 10.1260/1369-4332.14.4.699

[6] WUYue, ZHANG Jianliang, CAO Zhenggang. Form-finding analysis and engineering application of branching structures[J]. Journal of Building Structures, 2011, 32(11): 162-168. (in Chinese).

[7] LIU Xiliang, LIN Yan. Engineering application and research of cast-steel joints [J]. Progress in Steel Building Structures, 2004, 6(1): 12-19. (in Chinese).

[8] QIANG Sheng. Botany[M]. Higher Education Press, 2009. (in Chinese).

[9] HAN WenXuan. Review on the mechanism models of allometric scaling laws: 3/4 VS. 2/3 power[J]. Journal of Plant Ecology, 2008, 32(4): 951-960. (in Chinese).

[10] LIANG Li, GUO Yuming. Correlation study of biomechanical properties and morphological characteristics of crop stalks [J] Transactions of the Chinese Society of Agricultural Engineering, 2008, 24(7): 1-6. (in Chinese).

[11] Zhang Zhao, Chen Huazhou, et al. Finite element analysis of cast steel of Tianjin Meijiang convention and exhibition center [J]. Steel Construction, 2010, 25(11): 19-22. (in Chinese).

[12] JIA Lianguang, DU Qin. Analysis on the load carrying capacity of cast steel tubular joints used in diagonal frame structure [J]. Journal of Shenyang Jianzhu University(Natural Science), 2011, 27(5): 852-858. (in Chinese).

[13] Fan Zhong, Peng Yi, et al. Design of polyhedral steel casting joint for national stadium in Beijing[J]. Steel Construction, 2006, 21(5): 1-6. (in Chinese).

[14] HALDIMANN-STURM S C, NUSSBAUMER A. Fatigue design of cast steel nodes in tubular bridge structure[J]. International Journal of Fatigue, 2008, 30(3): 528-537.

DOI: 10.1016/j.ijfatigue.2007.03.007

[15] LU Yunxiang, CAI Yuanqi. Analysis of ultimate load and mechanisms of failure in large cast steel joints[J]. Journal of Chongqing University, 2010, 33(12): 71-77. (in Chinese).
