Structural Optimization of the Telescopic Boom of a Certain Type of Truck-Mounted Crane

Abstract:

Parametric finite element model for a commonly used telescopic boom structure of a certain type of truck-mounted crane has been established. Static analysis of the conventional design configuration was performed first. And then an optimization process has been carried out to minimize the total weight of the telescopic structures. The design variables include the geometric shape parameters of the cross-sections and the integrated structural parameters of the telescopic boom. The constraints include the maximum allowable equivalent stresses and the flexure displacements at the tip of the assembled boom structure in both the vertical direction and the circumferential direction of the rotating plane. Compared with the conventional design, the optimization design has achieved a significant weight reduction of up to 24.3%.

• Periodical: Applied Mechanics and Materials (Volumes 548-549)
• Pages: 383-388
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.548-549.383
• Online since: April 2014
• Authors: Zhi Wei Chen*, Zhe Cui, Yi Jin Fu, Wen Ping Cui, Li Juan Dong, Wen Guang Jiang
• Keywords: Optimization Analysis, Parametric Finite Element Model, Telescopic Boom, Truck-Mounted Crane

References

[1] Peng Cheng, Gang Han. Finite element analysis and structure optimization of truck crane Telescopic boom [J]. Construction machinery, 2012(8) : 88-91.

[2] Cheng-Qi Zeng, Liang-Bao Wei. Finite element parametric analysis of crane telescopic boom[J]. Construction machinery and equipment, 2010 (5): 82-84.

[3] Wen-Rui Jiao, Qing-Hua Kong. Finite element analysis of box structure telescopic boom of truck crane [J]. Construction machinery, 2007(9) : 33-36.
