Investigation of Melting Current in Glass Tube Fuses

Abstract:

This paper presents a study of melting current in the commercial glass tube fuses to determine the duration of melt, maximum melting current and maximum power consumption of the fuse in a blowing circuit. A microcontroller is used as a device to measure and collect the values of current, voltage, and power consumption. In the experiments, the glass tube fuses rated of 0.5 A, 1 A, 2 A, 3 A, 5 A, 10 A, 15 A, and 20 A were used. The experimental results show that the melting time were approximately 0.05 s, 0.07 s, 0.11 s, 0.13 s, 0.18 s, 0.20 s, 0.28 s, and 0.40 s; the maximum of melting current were approximately 0.66 A, 1.17 A, 3.81 A, 13.77 A, 20.80 A, 25.05 A, 26.66 A, and 29.96 A; the maximum of blowing voltage were approximately 12.25 V, 12.25 V, 12.30 V, 12.15 V, 12.10 V, 12.29 V, 12.10 V and 12.20 V; and the maximum of blowing power consumption were approximately 7.53 W, 14.22 W, 45.57 W, 158.49 W, 224.38 W, 242.21 W, 230.63 W and 283.68 W respectively.

• Periodical: Applied Mechanics and Materials (Volumes 548-549)
• Pages: 760-765
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.548-549.760
• Online since: April 2014
• Authors: Chitphong Ketthanom*, Chaichana Chaijumrus
• Keywords: Fuse, Glass Tube Fuse, Melting Current, Melting Time

References

[1] Ch. Ketthanom, and C. Chaijumrus: A Study of Melting Current in Low-Power Glass Tube Fuses (in Thai), Engineering Journal of Siam University , Volumn 25, pp.33-41. (2012).

DOI: 10.4028/www.scientific.net/amm.548-549.760

[2] H. Kawaguchi, T. Terao, T. Babasaki, M. Yamasaki: Modeling of fuses for DC power supply systems including arcing time analysis, Telecommunications Energy Conference, 2007, INTELEC 2007, 29th International : pp.135-141. (2007), Rome, Italy.

DOI: 10.1109/intlec.2007.4448754

[3] T. Tanaka, and M. Yamasaki: Modeling of Fuses for Melting Time and Fusing Current Analysis, Telecommunications Energy Conference 2004, INTELEC 2004, 26th Annual International: pp.671-675. (2004), USA, Illinois, Chicago.

DOI: 10.1109/intlec.2004.1401542

[4] T.J. Eckert: Understanding Fuse Ratings. Product Compliance Engineering, PSES: pp.1-6. (2009), USA.

[5] R.K. Huang, and S. Nilsson: Fuse selection criteria for safety applications, Product Compliance Engineering (ISPCE), 2012 IEEE Symposium on 5-7 November 2012: pp.1-8. (2012), USA, Portland, OR.

DOI: 10.1109/ispce.2012.6398293

[6] Cooper Bussmann Industry: Fuses-Electronic PCB and Small Dimension, Data Sheet. (2012).

[7] Matsuo Electric Co., Ltd.: Micro Fuse, Product Data Sheet. (2007).

[8] Panasonic USA: Fuses & Fuse Resistors, Data Sheet. (2012).

[9] LittelFuse Inc.: Fuseology, Data Sheet. (2005).

[10] LittelFuse Inc.: Surface Mount Fuses, Data Sheet. (2012).
