PI Control of Proportional Valve-Cylinder Water Hydraulic System

Abstract:

Water hydraulic components have been developed rapidly in recent years. However many problems such as low lubricity and leakage limited the performance of them, especially water proportional valves. A proportional valve- hydraulic cylinder system with tap water as working medium is chosen as object to investigate the performance of water hydraulic system. With regarding to the weaknesses of the selected 4/3 proportional valve including lag, dead zone and nonlinearity, an integral separation PI arithmetic based close-loop controller is developed. Experiments results verified the electro-hydraulic proportional system of fast response speed and high accuracy.

• Periodical: Applied Mechanics and Materials (Volumes 548-549)
• Pages: 977-984
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.548-549.977
• Online since: April 2014
• Authors: Xin Ba, Xiao Hui Luo*, Xu Feng Zhao, Yu Quan Zhu
• Keywords: Closed Loop Systems, Integral Separation PI, Proportional Control, Water Hydraulic

References

[1] Yang Huayong, Zhou Hua, Some key problems of the water hydraulics, J. Chinese journal of mechanical engineering. 38(2002) 96-100.

[2] Majdic F., Pezdirnik J., Kalin M. Experimental validation of the lifetime performance of a proportional 4/3 hydraulic valve operating in water, J. Tribology International, 44(2011) 2013-(2021).

DOI: 10.1016/j.triboint.2011.08.020

[3] Takahashi, T., Yamashina, C., and Miyakawa, S., Development of water hydraulic proportional control valve, Proc. Proceedings of the Fourth JHPS International Symposiumon Fluid power, Tokyo, Japan, (1999) 549-554.

DOI: 10.5739/isfp.1999.549

[4] S-H. Park, Development of a proportional poppet-type water hydraulic valve. Proceedings of the Institution of Mechanical Engineers, J. Part C: Journal of Mechanical Engineering Science 223(2009)2099-2107.

DOI: 10.1243/09544062jmes1380

[5] Yang Huayong, Gong Yongjun, Zhou Hua. Development review of water hydraulic valve, J. China mechanical engineering, 15(2004) 84-88.

[6] V. Ž. Filipović , N. N. Nedić, PID Regulators, Kraljevo, Serbia, (2008).

[7] Yao Zhuting, Pan Hongxia, The application of PID arithmetic in the ramming system's orientation control, Proc. International Conference on Information, Networking and Automation, Kunming, China, 2(2010)2219-2222.

DOI: 10.1109/icina.2010.5636746

[8] Du Shuwang, Feng Zhilin, Fang Zhiming, Design of improved PID algorithm for position control of servo unit, Proc. 2010 International Conference on Computer and Communication Technologies in Agriculture Engineering (CCTAE 2010), 3(2010)333-338.

DOI: 10.1109/cctae.2010.5544561
