Quasi-Static Contact Analysis of an Inchworm-Type Piezoelectric-Driven Rotary Actuator via Finite Element Method

Abstract:

Measurement results of the output stepping rotary angle of a piezoelectric-driven rotary actuator by means of inchworm motion have been compared with results obtained from three-dimensional Finite Element Analysis (FEA). Comparison results showed a good quantitative agreement, and confirmed the validity and accuracy of the finite element method in the design and analysis of the inchworm-type rotary actuators. In addition, the effect of the gap between the stator and rotor on the working performance of the actuator was investigated by using FEA. With the increase of the gap, both the stepping rotary angle and the output torque of the rotor decrease significantly. Therefore, this factor must be taken into consideration in the design and machining of this kind of actuators.

• Periodical: Applied Mechanics and Materials (Volume 551)
• Pages: 115-120
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.551.115
• Online since: May 2014
• Authors: Ze Jun Li, Tao Cui, Hong Wei Zhao*, Jian Ping Li
• Keywords: Finite Element Analysis (FEA), Inchworm, Quasi-Static Analysis, Rotary Actuator

References

[1] M. Bexell, A.L. Tiensuu, J.Å. Schweitz, et al. Sensors and Actuators A: Physical, 43 (1994) 322-329.

DOI: 10.1016/0924-4247(93)00700-e

[2] J.P. Li, H.W. Zhao, H. Qu, et al. Sensors and Actuators A: Physical, 194 (2013) 269-276.

[3] S.C. Kim, S.H. Kim. Review of scientific instruments, 70 (1999) 2546-2550.

[4] H.W. Zhao, L. Fu, L.Q. Ren, et al. Review of Scientific Instruments, 84 (2013) 015006-015006-9.

[5] J. Li, R. Sedaghati , J. Dargahi, et al. Mechatronics, 15 (2005) 651-681.

[6] K. Kwon, N. Cho, W. Jang. JSME International Journal Series C, 47(2004) 803-811.

[7] P.E. Tenzer, R.B. Mrad. Mechatronics, IEEE/ASME Transactions on, 9 (2004) 427-435.

[8] S.H. Chang, C.K. Tseng, H.C. Chien. Ultrasonics, Ferroelectrics and Frequency Control, IEEE Transactions on, 46 (1999) 906-912.

[9] S.H. Chang, C.K. Tseng, H.C. Chien. Ultrasonics, Ferroelectrics and Frequency Control, IEEE Transactions on, 46 (1999) 897-905.

[10] H. Huang, H.W. Zhao, Z. Yang, et al. Review of Scientific Instruments, 83 (2012) 055002-055002-6.

[11] Y. Li, Q. Xu. Automation Science and Engineering, IEEE Transactions on, 8 (2011) 265-279.

[12] P.E. Tenzer, M.R. Ben. Mechatronics, 14 (2004) 515-531.

[13] Y.K. Yong, T.F. Lu, D.C. Handley. Precision engineering, 32 (2008) 63-70.

[14] H. Wang, X. Zhang. Mechanism and Machine Theory, 43 (2008) 400-410.
