Research of the Wheat Modeling Problems Based on Creator

Abstract:

In order to making the virtual experiment results close to or equivalent to the real environmental effects, in addition to model realistic scenes, also need more accurate dynamic model. In this paper, based on research of hydraulic steering paddy and wheat combine harvester, first, used three-dimensional geometric model transformation technology to convert Pro/E model to a identified geometric model in VP virtual reality systems, second, used classical dynamics equations to build the mathematical model of this vehicle dynamics, finally, used VC++ programs to connect this two models, constructed a behavioral model of complete physics properties. This behavior model is not only more realistic than the geometry model in motion, but also it follows the laws of physics movement. It can effectively strengthen the authenticity of virtual experiment, provide an important platform to start agricultural machinery virtual characteristics test, and this Modeling Method can provide a reference for other agricultural machinery virtual reality platform to build.

• Periodical: Applied Mechanics and Materials (Volume 551)
• Pages: 696-701
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.551.696
• Online since: May 2014
• Authors: Fei Wang, Rui Juan Chi*, Zhong Xiang Zhu, En Rong Mao
• Keywords: Creator, Mipmap, Scene Modeling, Texture Image

References

[1] Lance Williams. Pyramidal Parametrics[J]. Computer Graphics (SIGGRAPH'83 Proceedings), 1983, 17(3): 1~11.

DOI: 10.1145/964967.801126

[2] Francesco Bellotti, Riccardo Berta, Rosario Cardona, Alessandro De Gloria. An Architectural Approach to Efficient 3D Urban Modeling[J]. Computers & Graphics, 2011, 35(5): 1001~1012.

DOI: 10.1016/j.cag.2011.07.004

[3] R.M. Smelik, T. Tutenel, K.J. de Kraker, R. Bidarra. A declarative approach to procedural modeling of virtual worlds[J]. Computer & Graphics, 2011, 35(2): 352~363.

DOI: 10.1016/j.cag.2010.11.011

[4] XIE Feng, JIANG Tao. New algorithm and realization of Mipmap for texture rendering[J]. Applied Science and Technology, 2008, 35(4): 57~60. In Chinese.

[5] WANG Yan-hong, YANG Ping-li, QIU Xiao-peng, CHEN Hui. Application of the Simulation Modeling Software Package-Creator[J]. Computer Simulation, 2005, 22(7): 179~181. In Chinese.

[6] SUN Siliang, CHEN Ren, SUN Li, YAN Jie. Research on Key Techniques of Complex Tank Modeling Based on 3ds MAX/Creator/VP [J]. System Simulation Technology, 2010, 6(3): 241~246. In Chinese.

[7] XU Zheng, SHEN Xiao-yun, HAN Dan. Modeling Technology of Flight Visualization Database Based on Creator[J]. 2009, 35(9): 265~268. In Chinese.

[8] HONG Guang, LI Hong-ru, MU Jian-guo. The Simplification of the 3D Model Based on Creator[J]. Computer Simulation, 2004, 21(1): 57~58. In Chinese.

[9] Fu Jie. Study on Some Technical Problems in Real-time Rendering of Large-scale Scenes[D]. Xi an: Northwest University, 2009. In Chinese.

[10] DU Ying, WU Yu-guo, YOU Xiong. Research of Mipmap Textures for Global Terrain Environment[J]. Journal of Zhengzhou Institute of Surveying and Mapping, 2006, 23(5): 355~358. In Chinese.

[11] XU Zhe, ZHANG Bo-heng, BIAN Chuan-ping, ZHANG Min-yun, ZHANG Yan-xi, YAO Da-lei. Image Compression Processing Based on Wavelet[J]. Science Technology and Engineering, 2007, 7(7): 1462~1464. In Chinese.

[12] GAO Wei-ying, YUAN Di-ping, JIN Xue-sheng. Key Technologies for Building Massive Three-Dimensional Scene Based on Creator[J]. Computer Simulation, 2007, 24(7): 209~212. In Chinese.

[13] WANG Chen, ZHOU Jun-qing, LI Li-jun. Creator-Visualization simulation modeling technology[M]. Wuhan: Huazhong University of Science and Technology press, 2005: 172~192. In Chinese.

[14] YANG Li, LI Guang-yao. Urban simulation modeling tools-Creator software tutorial[M]. Shanghai: Tongji University press, 2007: 170~180. In Chinese.
