An Electrode Sets with a Cylindrical Cathode and a Platy Anode for Reclamation of TFT-LCD Surface

Abstract:

The low yield rate of ITO thin-films is well known in semiconductor production processes. In the current study, an electrode sets with a cylindrical cathode and a platy anode as a reclamation process for the nanoscale removal of the indium tin oxide (ITO) nanostructure from the color filter surface of TFT-LCD displays is presented. In the current experiment, the major interest lies in the features of the technology and the design of the cylindrical cathode and the platy anode for the electrochemical etching process. For this process a steep gradient of the platy anode provides large discharge mobility and a better removal effect. A thin platy anode, a small gap-width between the cylindrical cathode and the ITO surface, or a high flow rate of electrolyte corresponds to a higher removal rate of the ITO-layer. A large current flow combined with a high feed rate of the display also results in a fast removal rate. By establishing a recycling process for the ultra-precise removal of the thin-film nanostructure, the optoelectronic semiconductor industry can effectively recycle defective products with a reduction of both production costs and pollution.

• Periodical: Applied Mechanics and Materials (Volume 552)
• Pages: 341-344
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.552.341
• Online since: June 2014
• Authors: P.S. Pa*
• Keywords: Cylindrical Cathode, Display, Electrode Sets, Nanoremoval, Nanoscale, Platy Anode, Reclamation

References

[1] P.M. Lee, H.Y. Chen: IEEE Conference Proceeding, Vol. 1 (2005), p.780.

[2] K. Daeil, K. Steven: Int'l J. of Surface and Coatings Technology, Vol. 154 (2002), p.204.

[3] K.K. Shieh: International Journal of Industrial Ergonomics, Vol. 25 (2000), p.275.

[4] M. Datta, D. Landolt: Elector. Acta, Vol. 26 (1981) p.899.

[5] L. Cagnon, V. Kirchner, M. Kock, R. Schuster, G. Ertl, W.T. Gmelin, H. Kuck: Z. Phys. Chem. Vol. 217 (2003), p.299.

[6] W.M. Shen, The Study of Polishing of Electric Discharge-Machined Mold With ECM, M. Sc. Thesis, National Yunlin Institute of Techndogy, Taiwan , (1995).

[7] P.S. Pa: Journal of Materials Processing Technology, Vol. 195, No. 1-3 (2008), p.44.

[8] B.H. Kim, S.H. Ryu, D.K. Choi, C.N. Chu: Journal of Micromechanics and Microengineering, Vol. 15 (2005), p.124.

[9] H.A. McGeough: Principles of Electrochemical Machining, Chapman and Hall, London (1974), p.1.
