Aerodynamic Characteristics of NACA 23015 Landing Configuration with 20^o Flap in Simulated Rain

Abstract:

In our numerical simulation the heavy rain effects have been studied on the aerodynamic performance of 2D cambered NACA 23015 airfoil landing configuration with 20^o. We have used preprocessing software gridgen for creation of the landing configuration of the airfoil and then creating mesh around it. Fluent is used to solve the conservation equations. We have used discrete phase modeling (DPM) in Fluent to simulate the rain phenomenon in continuous phase flow by using two phase flow approach. In our study the coupling between the discrete and the continuous phase has been activated. In discrete phase model (DPM), we used the wall film model for the interaction of the continuous and discrete phase. The airfoil landing configuration exhibited significant decrease in lift and increase in drag for a given lift conditions in simulated rain. Post processing software like MATLAB, Tec plot and Origin are used to see the effects of the heavy rain and then results obtained are compared with the experimental results. Our numerical results in most of cases show similar trends with the experiments.

• Periodical: Applied Mechanics and Materials (Volume 555)
• Pages: 108-112
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.555.108
• Online since: June 2014
• Authors: Shahid Latif*, Zhou Hong, Muhammad Ismail
• Keywords: Aerodynamic Efficiency, Computational Fluid Dynamics (CFD), Heavy Rain, Lift, NACA 23015, Two Phase Modeling, Wall Film

References

[1] B. Landsberg, Accident Trends and Factors, Joseph T, " Nail General Aviation Safety Report, AOPA Air Safety Foundation, Frederick, MD, pp.3-6, (1993).

[2] P. Riordan, Weather extremes around the world, DTIC Document1974.

[3] R. V. Rhode, Some Effects of Rainfall on Flight of Airplanes and on Instrument Indication, DTIC Document1941.

[4] P. Haines and J. Luers, Aerodynamic penalties of heavy rain on landing airplanes, Journal of Aircraft, vol. 20, pp.111-119, (1983).

DOI: 10.2514/3.44839

[5] J. K. Luers and P. A. Haines, Experimental measurements of rain effects on aircraft aerodynamics, in AIAA 21 st Aerospace Sciences Meeting, (1983).

[6] J. K. Luers, Heavy Rain Effects on Aircraft, AIAA Pap, pp.83-0206, (1983).

[7] R. Hansman and M. Barsotti, The aerodynamic effect of surface wetting characteristics on a laminar flow airfoil in simulated heavy rain, in American Institute of Aeronautics and Astronautics, Aerospace Sciences Meeting, 23 rd, Reno, NV, (1985).

DOI: 10.2514/6.1985-260

[8] A. P. Craig and R. J. Hansman, AN EXPERIMENTAL LOW REYNOLDS NUMBER COMPARISON OF A WORTMANN FX67-Kl70 AIRFOIL, A NACA 0012 AIRFOIL, AND A, (1987).

DOI: 10.2514/3.45476

[9] J. Valentine, Airfoil performance in heavy rain, Transportation research record, (1994).

[10] J. Valentine and R. Decker, A Lagrangian-Eulerian scheme for flow around an airfoil in rain, International journal of multiphase flow, vol. 21, pp.639-648, (1995).

DOI: 10.1016/0301-9322(95)00007-k

[11] J. R. Valentine and R. A. Decker, Tracking of Raindrops in Flow over an Airfoil, Journal of Aircraft, vol. 32, pp.100-105, (1995).

DOI: 10.2514/3.46689

[12] T. Wan, J. -X. Lin, and H. -C. Kuan, Aerodynamic Analysis of Helicopter Rotor Blades in Heavy Rain Condition, (2013).

[13] T. Wan and S. -P. Pan, Aerodynamic Efficiency Study under the Influence of Heavy Rain via Two-Phase Flow Approach, in Proceedings of the 27th International Congress of Aeronautical Sciences (ICAS), Nice, France, (2010).

[14] T. Wan and H. Yang, Aerodynamic Performance Investigation of a Modern Blended-Wing-Body Aircraft under the Influence of Heavy Rain Condition, in Proceedings of the 27th International Congress of Aeronautical Sciences (ICAS), Nice, France, (2010).

[15] R. -M. Zhang and Y. -H. Cao, Mechanisms research of rain effects on airfoil aerodynamic performance, Flight Dynamics, vol. 29, pp.70-73, (2011).

[16] R. -m. ZHANG and Y. -H. CAO, Study of aerodynamic characteristics of an airfoil in rain, Journal of Aerospace Power, vol. 9, p.022, (2010).

[17] A. J. Bilanin, Scaling laws for testing airfoils under heavy rainfall, Journal of Aircraft, vol. 24, pp.31-37, (1987).

DOI: 10.2514/3.45407

[18] B. CAMPBELL and G. BEZOS, Steady-state and transitional aerodynamic characteristics of a wing in simulated heavy rain, (1989).
