Structural Analysis of Unloading Frame of Mine Tubular Belt Conveyor

Abstract:

Mine tubular belt conveyor is a special belt-conveyor which uses closed transportation way to transport material, Unloading frame is one of the important structures of its unloading device, and its structural strength affect the running conditions of the machine. For this purpose, based on a certain type of mine tubular belt conveyor, this paper introduced the structure design and force calculation of its unloading frame, and took structural strength and stiffness analysis by ANSYS. Analysis results showed that Unloading frame meet the design requirements, but for ensuring the normal operation of the machine, the welding quality of unloading frame should also be considered.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1112-1115
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1112
• Online since: May 2014
• Authors: Qi Jiang Ma*, Kai Song Wang, Fei Fei Li
• Keywords: FEA Analysis, Mine Tubular Belt Conveyor, Structure Design, Unloading Frame

References

[1] Y.J. Zhang, Y.C. Guo, K. Hu and C. Shen: First Application of Tubular Belt Conveyor in Coal Mine Underground in China (Coal Mine Machinery, 2013, China), P. 1-17. (In Chinese).

[2] K. Hu, Y.C. Guo and P. Y Wang: Finite element analysis on spandrel frame of driving drum based on CATIA (Machinery Desjgn & Manufacture, 2011, China), P. 25-26. (In Chinese).

[3] G.Y. Pu: ANSYS Workbench 12 based tutorials and Detailed examples (China waterpower press, China, 2010), P. 136-143. (In Chinese).

[4] J. Yu, Q.H. Wang : Materials for mechanical engineering (Metallurgical industry press, China, 2008), P. 135-137. (In Chinese).

[5] X.X. cheng: Welding and cutting metals (Petroleum university press, China, 1993), P. 4-5. (In Chinese).
