Modeling of the Radiation Properties of Flow around the Hypersonic Aircrafts

Abstract:

To research the radiation properties of heat flow around the aircrafts’ surface in hypersonic flight, a fusion algorithm to calculate the radiation of flow around hypersonic aircrafts is proposed in this paper. Firstly, the algorithm use the computational fluid dynamics (CFD) to calculate the basic aerodynamic parameters of the aircrafts which are inside boundary layer, such as pressure, density, etc. Subsequently, the model of the radiation of flow around aircrafts is built by using the engineering algorithm. Then, we can build the model of the radiation properties of heat flow around the surface of the aircrafts effectively. The result can reflect the distribution of the radiation of heat flow around surfaces of the aircrafts accurately, and provide data support to study its optical detection and thermal protection.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1338-1341
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1338
• Online since: May 2014
• Authors: Yang Sheng Zhao*, Xiao Ping Du
• Keywords: Algorithm (GA), Heat Flow, Hypersonic Aircrafts, Radiation Properties

References

[1] Brian R H, Richard A T, Scott A B, et al. X-33 computational aeroheating/ aerodynamic predictions and comparisons with experimental data. NASA/TP-2003-212160, (2003).

[2] Gnoffo P A. CFD validation studies for hypersonic flow prediction. In: 39th AIAA Aerospace Sciences Meeting and Exhibit, Reno, Nevada, AIAA2001-1025, 2001-01-01-08-11, 2001. 13.

DOI: 10.2514/6.2001-1025

[3] Li Xiao-wei, Fan Xu-ji. Virtual grid and navier-stokes computation for control-surface. Journal of Shanghai Jiao tong University, 2002, 2: 125-130.

[4] NETTERFIELD M P. Validation of a Navier-Stokes code for thermochemical non equilibrium flows[R]. AIAA92-2878.

DOI: 10.2514/6.1992-2878

[5] VOTTA R, et al. Hypersonic low-density aerothermodynamics of Orion-like exploration vehicle[J]. Journal of Spacecraft and Rockets, 2009, 46(4): 781-787.

DOI: 10.2514/1.42663

[6] GNOFFO P A. Applications of program LAURA to three dimensional AOTV flow fields[R]. AIAA86-0565.

[7] DONG Wei-zhong, DING Ming-song, Gao tie-suo, et al. The influent of thermo-chemical non-equilibrium model and surface temperature on heat transfer rate[J]. ACTA AERODYNAMICA SINICA, 2013, 31(6): 692-697.

[8] Huang Zhi-cheng, Cheng Yong-xin, et al. Aerospace aerodynamics[M]. Beijing: China aerospace press, 2005: 293-309.

[9] Anderson J D. Hypersonic and High Temperature Gas Dynamics. New York: Mc Graw-Hill Book Company, (1988).
