Kinematics Simulation of a New CVT Based on Virtual Prototype Technology

Abstract:

In order to study the kinetic characteristic of a new continuously-variable-transmission (CVT), a three-dimensional model of the CVT was first established by Pro/E solid design and it was saved as Parasolid file format. Then, a kinematics simulation model of drive system of the CVT was established by importing the Parasolid file into ADAMS and the simulation was realized by replacing the traction drive of elasto-hydrodynamic lubrication (EHL) oil film with the contact constraint joints between the input and output wheel discs and the intermediate idler wheels. The simulation results demonstrate that the three-dimensional simulation model of the CVT is accurate, and the equivalent drive system of the CVT is reasonable.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 1426-1429
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.1426
• Online since: May 2014
• Authors: Qing Dun Zeng*, Feng Zhe Tan
• Keywords: Kinematics Simulation, New CVT, Transmission Drive, Virtual Prototype Technology

References

[1] H. O. Zhang: Traction drive continuously variable transmission mechanics research (Chongqing University, Chongqing 2007). (in Chinese).

[2] B. J. Hamrock and D. Dowson: ASME J. Lubri. Tech. Vol. 99 (1977), p.15.

[3] Y. Chen: Automotive Engineering Vol. 30 (2008), p.938. (in Chinese).

[4] H. O. Zhang, W. K. Shi and D. T. Qin: Sichuan Ordnance J. Vol. 28 (2007), p.61 (in Chinese).

[5] Z. G. Li: Introductory Explanation and Example of ADAMS (National Defense Industry Press, Beijing 2006). (in Chinese).
