A 520MHz Wideband Variable Gain Amplifier

Abstract:

The design and realization of a wideband variable gain amplifier for RF system is presented. The cascade of LNA and controllable attenuation makes the design have a 0-90dB gain adjustment range. Special care is devoted to the solution of typical problems encountered in the design of the amplifier, such as signal shielding and power supply decoupling. The amplifier uses passive amplitude-frequency equalization, 0.1-460MHz band variation is less than 1dB, the 3dB bandwidth is up to 520MHz. The noise characteristic is low, the total input referred noise is less than 15.5nV⁄√¯Hz.
