The Simulation Study of Direct-Current Control Technology for Three-Phase Voltage Type Rectifier

Abstract:

The diode uncontrolled rectifier or the phase controlled rectifier is widely used in conventional rectifier link, thus the conventional rectifier link on the grid inject a large number of harmonics and reactive power, and they cause a severe grid “pollution”. This paper starts from the basic principles of the PWM rectifier, then the paper discusses the topological classification of three-phase PWM rectifier in detail. Based on topological structure, the paper builds the mathematical model of three-phase stationary coordinate system and two-phase rotating coordinate system. Based on space voltage vector, the paper studies PWM control method in-depth and simulates in Matlab/Simulink. The correctness of the theoretical study of three-phase voltage source PWM rectifier system is verified by the simulation results.

• Periodical: Applied Mechanics and Materials (Volumes 556-562)
• Pages: 2105-2109
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.556-562.2105
• Online since: May 2014
• Authors: Rong Jun*
• Keywords: Direct Current (DC), Rectifier, Simulation, Topology

References

[1] Zhang Xing, Zhang Chongwei. The research of reversible PWM converter space voltage vector control technology [J]. Proceedings of the csee, 2001., 2007: 37-42. (In Chinese).

[2] Zhu Pingping, Gao Yanxia, Zhou Yicheng. The new strategy of speed changed for sensorless BLDCM[J]. Power electronics technology. 2002, (4): 36-38 (In Chinese).

[3] Chen Zhijiang. The research of three-phase voltage source PWM rectifier[D]. The master thesis of huazhong university of science and technology 2006 (In Chinese).

[4] Jiang Yao. Three-phase voltage source PWM rectifier device research [D]. The master thesis of xian university of science and technology, 2008(In Chinese).

[5] Weng YingJun. The research and simulation voltage space vector PWM control Technology[J]. Journal of guizhou university of technology (natural science edition), 1999: 34-38. (In Chinese).

[6] Green AW, Boys JT，Gates GF. 3-phase voltage sourced reversible rectifier. IEEE Proceedings [J]．1988.

[7] Hong Naigang. The MATLAB Simulation of power electronics and electric drive control system. Beijing: China Machine Press, 2006 (In Chinese).

[8] Wu Jianjiang. The simulation practice of Pspice software[M]. The press of Harbin industrial university. 2001: 110-130 (In Chinese).
