A Visual Simulation Method for 2-D Complex Situation of Electromagnetic Environment

Abstract:

As the complex situation of electromagnetic environment is difficult to be analyzed and simulated visibly, interface program is developed based on the calculation module of Wireless Insite2.5 software. Equipments such as communication, radar, electronics resists and other radio devices are studied to build accurate theoretic models. Moreover, a method for creating software receivers quickly in MATLAB is proposed and other equipment models are created automatically just based on the parameters of equipments in the same way. Then, situations of time, frequency and energy-domain are calculated successfully with using Wireless Insite2.5. Complex 2-D situation of electromagnetic environment is displayed in the 2-D map by using MATLAB map display technology. At last, Display and query visualization for complex situation of electromagnetic environment is realized by designing a visual data query tool of mouse.

• Periodical: Applied Mechanics and Materials (Volumes 568-570)
• Pages: 1516-1519
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.568-570.1516
• Online since: June 2014
• Authors: Meng Zhong Hu, Tong Sheng Yi, Jia Liang Pan
• Keywords: Complex Situation, Electromagnetic Environment, Visual Simulation, Wireless Insite
