Passivity-Based Controller of Tri-State Boost Converter

Abstract:

A novel boost converter named tri-state boost converter is introduced in this paper. According to the operation principle of the tri-state boost converter, the Euler-Lagrange model is set up. Based on the passivity-based control theory and Euler-Lagrange model, a passivity-based controller of the tri-state boost converter is designed. By damping injecting, the input current and output voltage of the tri-state boost converter can reach the desired equilibrium values rapidly. The speed of the tri-state boost converter to reach the desired equilibrium values varies when the damping values changes. The controller is simple to design and makes the tri-state boost converter having better dynamic and steady performances. The passivity-based controller proposed in the paper is proved feasible by simulation results.

• Periodical: Applied Mechanics and Materials (Volumes 571-572)
• Pages: 944-949
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.571-572.944
• Online since: June 2014
• Authors: Qi Tang*, Jiu He Wang, Jing Wei Hu
• Keywords: Damping Injecting, Euler-Lagrange Model, Passivity-Based Control Method, Tri-State Boost Converter

References

[1] Fei Zhang, Jianping Xu, and Ping Yang. Tri-State Boost PFC Converter with High Input Power Factor. Proc. IEEE International Power Electronics and Motion Control Conf, 2012, pp.1626-1629.

DOI: 10.1109/ipemc.2012.6259078

[2] K. Viswanathan, R. Oruganti, and D. Srinivasan. A novel tri-State boost converter with fast dynamics. IEEE Transactions on Power Electronics , Vol. 17, No. 5, 2002, pp.677-683.

DOI: 10.1109/tpel.2002.802197

[3] TANG Qi, WANG Jiu-he, HU Jing-wei. Passivity based control method of the tri-state boost converter. Proceedings of the CSEE, Vol. 33, Supplement, 2013, pp.170-174.

[4] ZHANG Fei, XU Jian-ping, WANG Jin-ping, etc. Tri-state Boost PFC converter with fast dynamic response. Electric Machines and Control, Vol. 15, No. 1, 2011, pp.14-16.

[5] LIU jin-bo, MING Wen-long. Mathematical Model and Its Input/Output Feedback linearization Nonlinear Control Method of Tri-state Boost Type DC/DC Converter. Proceedings of the CSEE, Vol. 30, No. 27, 2010, pp.55-61.

DOI: 10.1109/icit.2010.5472720

[6] C.Y. Chan. Development of non-linear controllers for a tri-state boost converter. Proc IET Power Electronics , Vol. 5, No. 2, 2012, pp.68-72.

DOI: 10.1049/iet-pel.2011.0077

[7] HU Jing-wei, WANG Jiu-he, TANG Qi. Passivity based controller of Cuk converter based on EL model. Journal of Beijing Information Science and Technology University, Vol. 28, No5, 2013, pp.67-72.

[8] WANG Jiu-he. Passivity based controller of Boost type DC/DC converter based on EL model. Journal of Beijing Information Science and Technology University, Vol. 27, No. 5, 2012, pp.18-19.
