Combined CNF with LQR in Improving Ride and Handling for Ground Vehicle

Abstract:

This paper presents and analyses a performance comparison between a Linear Quadratic Regulator (LQR) and Composite Nonlinear Feedback (CNF) controllers for an active anti-roll bar (ARB) system. The anti-roll bar system has to balance the trade-off involving ride comfort and handling performance. The basic vehicle dynamic modelling with four degree of freedom (DOF) on half car model is proposed. The design model is validity and the performances of roll angle and roll rate under control of LQR and CNF controller are achieved by using simulation analysis. Both two controllers are modeled in MATLAB/SIMULINK environment. It has to be determined which control strategy delivers better performance with respect to roll angle and the roll rate of half vehicle body to achieve this goal. The result shows, the CNF LQR fusion control strategy improve the performance compared to LQR and CNF control strategy.

• Periodical: Applied Mechanics and Materials (Volume 575)
• Pages: 749-752
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.575.749
• Online since: June 2014
• Authors: Noraishikin Zulkarnain*, Hairi Zamzuri, Saiful Amri Mazlan
• Keywords: Active Anti-Roll Bar, Handling, Optimal Control, Ride Comfort

References

[1] T.J. Yuen, R. Rahizar, Z.A. Mohd Azman, A. Anuar and D. Afandi, Design Optimization of Full Vehicle Suspension Based on Ride and Handling Performance, in Proc. the FISITA 2012 World Automotive Congress Lecture Notes in Electrical Engineering, vol. 195, pp.75-86, (2013).

DOI: 10.1007/978-3-642-33835-9_8

[2] P.H. Cronje, P. S. Els, Improving off-road vehicle handling using an active anti-roll bar, Journal of Terramechanics, vol. 47, no. 3, pp.179-189, June (2010).

DOI: 10.1016/j.jterra.2009.09.003

[3] H.B. Pacejka, Tyre and Vehice Dynamics, Butterworth Heine-mann, (2002).

[4] N. Zulkarnain, F. Imaduddin, H. Zamzuri and S.A. Mazlan, "Application of an Active Anti-roll.

[5] bar system for enhancing vehicle ride and handling, " IEEE Colloquium on Humanities, Science and Engineering , pp.260-265, December (2012).

[6] B.M. Chen, A Hard-Disk-Drive Servo System Design Using Composite Nonlinear-Feedback Control With Optimal Nonlinear Gain Tuning Methods, IEEE Trans. Ind. Electron., vol. 57, no. 5, p.1735–1745, May (2010).

DOI: 10.1109/tie.2009.2032205

[7] M.F. Ismail, K. Peng, N. Hamzah, Y.M. Sam, M.K. Aripin and M.H. Che Hasan, A linear model of quarter car active suspension system using composite nonlinear feedback control, " In Research and Development (SC, OReD), 2012 IEEE Student Conference , pp.98-103.

DOI: 10.1109/scored.2012.6518619

[8] N. Zulkarnain, H. Zamzuri and S.A. Mazlan, Improving Vehicle Handling using Composite Nonlinear Feedback Controller for Active Anti-roll Bar System,: submitted to Journal of Control Engineering and Applied Informatics (2014).

DOI: 10.4028/www.scientific.net/amm.663.146
