A Bank of Finite Memory Filters for Fault Detection and Adjusting Detection Latency

Abstract:

This paper proposes a new fault detection scheme using a bank of finite memory filters for discrete-time dynamic systems with multiple sensors. In the proposed scheme, fault detection is carried out by testing the consistency of two filtered estimates, which are obtained from the primary estimation filter and the auxiliary estimation filter using a bank of finite memory filters, respectively. Detection latency is considered as one of important performance criteria and focus on the improvement of detection latency even for high threshold value. Through extensive computer simulations for the F-404 engine system, it is shown that detection latency can be adjusted by the window length. Simulation results show that the trade-off between the fast detection performance and the noise-suppressing estimation performance should be needed for the proposed fault detection scheme in real applications.

• Periodical: Applied Mechanics and Materials (Volume 575)
• Pages: 811-819
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.575.811
• Online since: June 2014
• Authors: Pyung Soo Kim*, Eung Hyuk Lee, Mun Suck Jang, Ki Sun Song
• Keywords: Detection Latency, F-404 Engine System, Fault Detection, Finite Memory Filter

References

[1] J. van der Geer, J.A.J. Hanraads, R.A. Lupton, The art of writing a scientific article, J. Sci. Commun. 163 (2000) 51-59. Reference to a book.

[2] W. Strunk Jr., E.B. White, The Elements of Style, third ed., Macmillan, New York, 1979. Reference to a chapter in an edited book.

[3] G.R. Mettam, L.B. Adams, How to prepare an electronic version of your article, in: B.S. Jones, R.Z. Smith (Eds. ), Introduction to the Electronic Age, E-Publishing Inc., New York, 1999, pp.281-304.

[4] R.J. Ong, J.T. Dawley and P.G. Clem: submitted to Journal of Materials Research (2003).

[5] P.G. Clem, M. Rodriguez, J.A. Voigt and C.S. Ashley, U.S. Patent 6, 231, 666. (2001).

[6] Information on.

[1] C. Angeli and A. Chatzinikolaou, On-line fault detection techniques for technical systems: A survey, International Journal of Computer Science & Applications. 1 (2004) p.12–30.

[2] I. Hwang, S. Kim, Y. Kim, and C.E. Seah, A survey of fault detection, isolation, and reconfiguration methods, IEEE Trans. Control Systems Technology. 18 (2010) p.636–653.

DOI: 10.1109/tcst.2009.2026285

[3] T. Kobayashi and D. L. Simon, Enhanced bank of Kalman filters developed and demonstrated for in-flight aircraft engine sensor fault diagnostics, Research and Technology, NASA Glenn Research Center at Lewis Field. 2005-213419 (2005) p.25–26.

DOI: 10.1115/gt2004-53640

[4] N. Tudoroiu and K. Khorasani, Satellite fault diagnosis using a bank of interacting Kalman filters, IEEE Trans. Aerosp. Electron. Syst. 43 (2007) p.1334–1350.

DOI: 10.1109/taes.2007.4407462

[5] W. Xue, Y. Guo, and X. Zhang, Application of a bank of Kalman filters and a robust Kalman filter for aircraft engine sensor/actuator fault diagnosis, International Journal of Innovative Computing, Information and Control. 4 (2008) p.3161–3168.

DOI: 10.1109/icicic.2007.3

[6] W. H. Kwon, P. S. Kim, and S. H. Han, A receding horizon unbiased FIR filter for discrete-time state space models, Automatica. 38 (2002) p.545–551.

DOI: 10.1016/s0005-1098(01)00242-4

[7] P. S. Kim, An alternative FIR filter for state estimation in discrete-time systems, Digital Signal Processing. 20 (2010) p.935–943.

DOI: 10.1016/j.dsp.2009.10.033

[8] Y. S. Shmaliy, Linear optimal FIR estimation of discrete time-invariant state-space models, IEEE Trans. on Signal Processing. 58 (2010) p.3086–3096.

DOI: 10.1109/tsp.2010.2045422

[9] Y. S. Shmaliy and O. Ibarra-Manzano, Time-variant linear optimal finite impulse response estimator for discrete state-space models, International Journal of Adaptive Control and Signal Processing. 26 (2012) 95–104.

DOI: 10.1002/acs.1274

[10] P. S. Kim, A finite memory filtering for end-to-end available bandwidth estimation, International Journal of Control, Automation, and Systems. 11 (2013) p.1–5.

DOI: 10.1007/s12555-012-0329-1

[11] P. S. Kim, A computationally efficient fixed-lag smoother using recent finite measurements, Measurement. 46 (2013) p.846–850.

DOI: 10.1016/j.measurement.2012.09.021

[12] P. S. Kim, M. S. Jang, and E. H. Lee, A discrete time-varying finite memory smoother and its application in fault detection, ICIC Express Letters - An International Journal of Research and Surveys. 8 (2014) p.957–962.

[13] L. Pelkowitz and S. C. Schwartz, Asymptotically optimum sample size for quickest detection, IEEE Trans. Aerosp. Electron. Syst. 23 (1987) p.263–272.

DOI: 10.1109/taes.1987.313381

[14] R. W. Eustace, B. A. Woodyatt, G. L. Merrington, and A. Runacres, Fault signatures obtained from fault implant tests on an F404 engine, J. Eng. Gas Turbines Power. 116 (1994) p.178–183.

DOI: 10.1115/1.2906789
