Study on Electrical Parameter Frequency of the Out-of-Step Oscillation Center

Abstract:

Out-of-step splitting is an emergency strategy to trigger splitting devices to separate power systems into several sub-regions through capturing oscillation center before the collapse of the system. How to position the oscillation center rapidly and accurately is a key procedure in out-of-step splitting field. This paper proposes a new method to position the oscillation center based on electrical parameter frequency. Firstly the current and voltage frequency variation characteristic of out-of-step tie line is analyzed. Secondly, the electrical parameter frequency variation rules are summarizes, i.e. curves of buses voltage frequency of the oscillation center line change continuously without intersection and they have the opposite variation trend. At last, the oscillation center can be positioned accurately within half out-of-step cycle by constantly monitoring electrical parameter frequency of the transmission tie lines. The accuracy and rapidity of the method are certified by the simulation results of four machine two regional power system.

• Periodical: Applied Mechanics and Materials (Volume 577)
• Pages: 536-540
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.577.536
• Online since: July 2014
• Authors: Jian Yang*, Fei Tang, Qing Fen Liao, Yi Fei Wang
• Keywords: Current Frequency, Oscillation Center, Out-of-Step, Voltage Frequency

References

[1] Gao Peng, Wang Jianquan, Zhou Wenping, et al. Implementation scheme and simulation on capturing the out-of-step interface[J]. Automation of Electric Power Systems, 2005, 29(12): 38-43.

[2] Zhang Baohui, Zhang Yigang. Study on principle of power system separation device based on local electrical parameter[J]. Proceedings of the CSEE, 2001, 21(12): 67-72.

[3] Gao Peng, Wang Jianquan, Zhou Wenping. Improvement of the apparent impedance angle separation criterion[J]. Automation of Electric Power Systems, 2005, 28(24): 36-40.

[4] Gao Peng, Wang Jianquan, Zhou Wenping, et al. Theoretical study on capturing the separation interface of out-of-step based on reactive power[J]. Automation of Electric Power Systems, 2005, 29(5): 15-20.

[5] Li Li, Liu Yutian. Adaptive out-of-step detecting composite criterion for splitting surface[J]. Automation of Electric Power Systems, 2009, 33(22): 40-43.
