The Vibration Characteristics of the Hydropower Plant with a Certain Cross Flow Hydro-Turbine Generating Units and its Earthquake Response Analysis

Abstract:

To consider the safety of a certain cross flow hydro-turbine generating units and the hydropower plant, the finite element model of the plant and units are established by ANSYS, with which the resonance check is carried out. Meantime, the spectrum analysis method is used to present an earthquake response analysis according to the relative specifications, and the earthquake reaction condition in different directions of the characteristic monitoring points in main height is obtained, then the vibration characteristics of the hydropower plant and the effect of the earthquake load are analyzed. The research gives evidence and reference to make sure of the plant structure safety and the healthy operation for hydro-turbine.

• Periodical: Applied Mechanics and Materials (Volume 577)
• Pages: 541-545
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.577.541
• Online since: July 2014
• Authors: Zhen Yu Ouyang*
• Keywords: Earthquake Response Analysis, Finite Element Method (FEM), Turbine Hydropower Station, Vibration Analysis of Plant

References

[1] Wen Song, Libang Su, Yunhe Liu, Shouyi. Bulb Tubular hydropower plant dam seismic analysis [J]. Northwest Agriculture and Forestry University (Natural Science). 2007, 35 (7): 202-206.

[2] Jijian Lian, Haijun Wang, Rixuan Wang Research on dynamic characteristics of Riverbed Hydropower Plant [J]. Water Conservancy and Hydropower Engineering, 2004, (08), : 38-40.

[3] Yuanfang Huang The three gorges project turbines making several major technical problems [J]. Hydroelectric, 1998 (4): 36-39, 62.

[4] Yuxin Dong Water turbine vibration [M]. Dalian: Dalian University of Technology Press, (1989).

[5] China Institute of Water Resources and Hydropower Research. For seismic design of hydraulic structures (DL5073-2000) [S]. Beijing: China Electric Power Press, (2000).
