Research on the Equivalence and the Mechanical Performance of the Model of Steel-Concrete Joint

Abstract:

The hybrid girder cable-stayed bridge of railway has been applied in the design of the Yongjiang Bridge, it is first used in our country as yet. The mechanical performance of the steel-concrete joint as the key position of the hybrid girder cable-stayed bridge determine its safety and durability. Based on the background of a bridge in Zhejiang Province , the spatial finite-element model of model and actual bridge is developed to study the mechanical performance and verify the feasibility of design method of the model. As it turned out, the model can better reflect the stress of actual bridge. The trend of the stress of the key plates of its is basically identical. The steel-concrete joint can perfectly accomplish the transmission of the stress function. Bearing plate plays a vital role in the stress transfer, the function of the PBL shear connector near the bearing plate is obvious.

• Periodical: Applied Mechanics and Materials (Volumes 578-579)
• Pages: 168-172
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.578-579.168
• Online since: July 2014
• Authors: Ya Dong Yao, Qian Hui Pu, Chao Yi Yao
• Keywords: Bearing Plate, PBL Shear Connector, Shear Lag Effect, Steel-Concrete Joint

References

[1] Altmann R, Maquoi R, Jaspart J P. EXPERIMENTAL-STUDY OF THE NONLINEAR BEHAVIOR OF BEAM-TO-COLUMN COMPOSITE JOINTS[J]. JOURNAL OF CONSTRUCTIONAL STEEL RESEARCH. 1991, 18(1): 45-54.

DOI: 10.1016/0143-974x(91)90052-3

[2] ZHANG Zhong-xian, HUANG Caiping, DANG ZHijie. Static experiments of steel-concrete composite structure of hybrid cable-stayed bridges[J]. Huazhong Univ. of Sci. & Tech. (Natural Science Edition) 2010(05): 117-120. In Chinese.

[3] Kaili, Chen Jiezao, Wang Qunhui, An. Model tests on steel-concrete joining section of main girder of a cable-stayed bridge [J] CHINA CIVIL ENGINEERING JOURNAL: 2006, 39(3): 86-90. In Chinese.

[4] Zhang Qinghua Li Qiao. Mechanical features of cable-girder anchorage for cable-stayed bridgeswith steel box girders[J] CHINA CIVIL ENGINEERING JOURNAL: 2012, 09: 100-107. In Chinese.

DOI: 10.4028/www.scientific.net/amm.423-426.1259

[5] LIU Minghu, XU Guoping, LIU Feng. Study and Design of Steel-concrete Joint Part of Hybrid Girder of Edong Bridge[J] Journal of Highway and Transportation Research and Development: 2010, 12(27): 78-85. In Chinese.

[6] Fan Jiansheng, Nie Jianguo, Lu Jianfeng, Zhang Gejun, Yang Xiaobin,. Test on the composite joint section between steel box girder and concrete tower of a cable-stayed bridge [J] CHINA CIVIL ENGINEERING JOURNAL: 2008, 07(41): 61-66. In Chinese.

[7] Ahn J H, Kim S H, Jeong Y J. Shear behaviour of perfobond rib shear connector under static and cyclic loadings[J]. MAGAZINE OF CONCRETE RESEARCH. 2008, 60(5): 347-357.

DOI: 10.1680/macr.2007.00046
