Finite Element Analysis of Steel Frame Beam-Column Irregular Joints with a Strengthened External Diaphragm

Abstract:

Finite element analysis methods were conducted to investigate the seismic performance of panel zone at the connection of square steel column and two H-shaped beams with different heigth level by using ABAQUS. Compared with the previous test ,which verifies the correctness of finite element model. The paper sets up a total of 11 finite element analysis models, The changes of the web thickness, thickness of beam flange, diameter-thickness ratio in the finite element analysis models are studied, Which affect the beam end joint load - displacement curves and stress distribution.Studies have showed that: the beam flange thickness ratio and the beam offset ratio has insignificant influence on the load-displacement curves. The diameter to thickness ratio have sharp influence on the load-displacement curves.

• Periodical: Applied Mechanics and Materials (Volumes 578-579)
• Pages: 274-277
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.578-579.274
• Online since: July 2014
• Authors: Wei Ning Sui*, Qing Ze Shi, Zhan Fei Wang, Xue Bai
• Keywords: Finite Element Analysis (FEA), Irregular Joints, Joint with External Diaphragm, Mechanical Property, Steel Frame

References

[1] Tsai K C. Steel beam-column joints in seismic moment resisting frames[D]. Department of Civil Engineering, University California, Berkeley，(1988).

[2] Nakashima M et al. Test of welded beam-to-column subassemblies I：global behavior[J]. Journal of Structural Engineering ，1998，124(11)：1236-1244.

[3] Chen S J, Tsao Y C and Chao Y C. Enhancement of ductility of existing seismic steel moment connections[J]. Journal of Structural Engineering，2001, 127(2)：129-126.

DOI: 10.1061/(asce)0733-9445(2001)127:5(538)

[4] LIU Hong-bo, XIE Li-li, SHAO Yong-song. Finite element analyses of the rigid connections with steel box columns and I section beams[J]. Journal of Harbin Institute of technology. 2007，39(8)：1211-1215.

[5] XUE Jianyang, LIU Zuqiang, PENG Xiuning, HU Zongbo Experimental study on seismic behavior of abnormal joints in large-scale power plant steel structures [J]. journal of Building structures (2011).

[6] Susumu KUWAHARA, Takehito KUMANO, Kazuo INOUE. The elasto-plastic behaviors of joint panels at the connection of rectangular steel column and two H-shaped beams with different depth, Journal of Struct. Constr. Engng, AIJ, 2000(533): 175-181.

DOI: 10.3130/aijs.65.175_4

[7] SUI Weining，BAI Xue，LI Guo-chang. Finite Element Analysis on Steel Beam-Column Joints Strengthened by Plate Ring with Different Details in the Panel Zone [J] Journal of Shenyang Jianzhu University. 2013（7）：675-681.

[8] SUI Weining，Bai Xue，LI Guo-chang，Bai Liting. Nonlinear Finite Element Analysis of Steel Beam-to-column Joints With External Annular Plate and an offset in right and left beam positions,   Industrial Construction（supplement ）2013（43）：313-316.
