Mechanical Properties and Calculation Method for Monolayer Cable Net Glass Curtain Wall under Fire Conditions

Abstract:

The developing trend of large scale curtain wall structure system is monolayer cable net glass curtain wall, so it’s important and necessary to study the corresponding calculation method and mechanical properties under fire conditions. The changing rule of the displacement and the maximum cable force with the temperature was analyzed by making series of numerical calculations, and the principle for determining critical temperature was deeply discussed upon the basis of the numerical simulation results. The critical temperature table considering different spans, grid dimensions and cable diameters is given, and the influence on critical temperature has also been studied when initial prestressed force of vertical cable is relatively small. Some suggestions are proposed finally.

• Periodical: Applied Mechanics and Materials (Volumes 580-583)
• Pages: 2583-2588
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.580-583.2583
• Online since: July 2014
• Authors: Ling Feng Gong*, Yin Bai, Si Qi Li
• Keywords: Critical Temperature, Fire Disaster, Glass Curtain Wall, Mechanical Property, Monolayer Cable Net, Steel Structure

References

[1] Wu Peng, Zhang Liangping, Dong Shilin, Wang Zhe. The application and research of flexible support systems for glass architectures[J]. Spatial structures, 2002, 8(2): 31-37. (in Chinese).

[2] Shi Yon-jiu, Bai Yin, Wang Yuanqing. Study on Performance-based Fire-resisting Design and Key Technique thereof for Large Space Steel Structures[A]. Cui Jinghao, Proceedings of the fifteenth national conference on structural engineering[C], The fifteenth national conference on structural engineering, Jiaozuo, 2006, Beijing: Engineering Mechanics Journal Press, 2006: 119-126. (in Chinese).

[3] Zhang Haoyu, Zheng Wenzhong. Mechanical property of steel strand at high temperature [J]. Journal of Harbin Institute of technology, 2007, 39(6). (in Chinese).

[4] Zhang Qilin. Cable and membrane structure [M]. Shanghai: Tongji University Press, 2002: 32-37. (in Chinese).

[5] Bai Yin, Shi Yongjiu, Wang Yuanqing. Theoretical Analysis and Numerical Simulation on Mechanical Properties of Large Space Cable-Supported Structures under Fire Conditions [J]. Science in China: Series E, 2009, (8): 2340-2349.

DOI: 10.1007/s11431-008-0194-6

[6] Feng Ruoqiang, Wu Yue, Shen Shizhao. Static performance of single-layer plane cable net glass curtain in consideration of glass panel [J]. Journal of Building Structures. 2005, 26(4). (in Chinese).

[7] China Association for Engineering Construction Standardization. CECS 127-2001. Technical Specification for Point Supported Glass Curtain Wall [S]. Beijing, (2001).

[8] Wang Yuanqing, SUN Fen, SHI Yong-jiu, Luo Yi, Xu Yue. The Deflection Performance Analysis of Single-layer Cable Net for Point2supporting Glass Curtain Under Horizontal Load[J]. Building Science, 2006, 22(2): 23-26. (in Chinese).

[9] Feng Ruoqiang, Wu Yue, Shen Shizhao. Static performance of single2layer plane cable net glass curtain in consideration of glass panel. Journal of Building Structures, 2005, 26(4): 99-105. (in Chinese).

[10] Hassani, S. K., Shields, T. J., and Silcock, G. W., An Experimental Investigation into the Behaviour of Glazing in Enclosure Fire[J]. Applied Fire Science, 1994, 4(5): 303-323.

DOI: 10.2190/f6vd-tdlw-c6e4-c5h9
