Application of Stereo Vision Measurement Technology in the Detection of Round Hole

Abstract:

In precision machining, we often detect the location of some round holes or other geometric parameters. Given the disadvantages of traditional method is contacted, artificial and time-consuming, this paper has proposed a image measurement method based on stereo vision. We use the method of digital image processing to perform the denoising, binarization, edge detection, and centralized location of the orifice image, and analyze the accuracy of the hole machining and arrangement. Experimental results show that the error of image measurement proposed is less than 0.14mm, which meets the general requirements of the hole measurement precision and is applicable to the online measurement that the accuracy requirement is not high and the task with large amount of object to detect.

• Periodical: Applied Mechanics and Materials (Volumes 580-583)
• Pages: 2805-2809
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.580-583.2805
• Online since: July 2014
• Authors: Qiang Wang, Xi Min Cui*, Cong Li, Jia Jie Cui, Liang Jian Li
• Keywords: Edge Detection, Online Measurement, Round Hole, Stereo Vision

References

[1] P LIU. J WANG. S Q WANG. Journal of Applied Optics 2011, 32 (2), 291-295.

[2] H W LENG. C G XU. Z W FENG. Journal of Image and Graphics 2010, 15(7), 1084-1090.

[3] J M LIANG. H M GAO. Transactions of the China Welding Institution 2006, 27 (2), 102-105.

[4] G J ZHANG. Machine Vision. Beijing, Science Press, (2005).

[5] T A. Clarke, J G Fryer. The Development of Camera Calibration Methods and Models. Photogramm. Rec 1998, 16 (91), 51-66.

[6] L S LIU. Y ZHANG. H Q LU. Journal of Optoelectronics laser 2005, 16 (8), 993-996.

[7] Q B TONG. Z L DING. Y B DONG. Journal of Jilin University(Engineering and Technology Edition) 2009, 39 (1) 154-159.

[8] Jensen K. Anastassiou D. Sub-pixel edge localization and the interpolation of still images. Trans on Images Processing 1995, 4 (3) 285-295.

DOI: 10.1109/83.366477
