Analysis of Feed-Direction Burr Formation in Micro-Turning

Abstract:

A three-dimensional model of micro-turning using the finite element method (FEM) is created in this paper to analyzed the formation mechanism and influencing factors of feed-direction burr in micro-turning. According to the simulation and analysis result, in micro-turning,the deformation of the workpiece feed direction end is the combined action of the plastic bending deformation and shear slip deformation, and plastic bending deformation influences burr height and shear slip deformation affects the burr root thickness. Meanwhile, due to the amount of material involved in different deformation actions is changed, compared with conventional scale cutting, the various influencing factors have significant differences effect on the size of burr.

• Periodical: Applied Mechanics and Materials (Volume 590)
• Pages: 299-303
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.590.299
• Online since: June 2014
• Authors: Jin Gui Huang, Juan Huang, Cheng Yang, Gui Cheng Wang*
• Keywords: Burr, Feed-Direction Burr, FEM, Formation, Micro-Turning

References

[1] Dornfeld. Recent Advance in Mechanical Micro machining[J]. CIRP ANNALS MANUFACTURING TECHNOLOGY, 2006, 55(2): 745-768.

[2] Mustapha Abouridouane, Fritz Klocke, et al. A New 3D multiphase FE Model for Micro Cutting Ferritic-Pearlitic Carbon[J]. CIRP Annals - Manufacturing Technology, 2012, 61: 71-74.

DOI: 10.1016/j.cirp.2012.03.075

[3] Malekian M, Mostofa M G, Park S S, et al. Modeling of Minimum Uncut Chip Thickness in Micro Machining of Aluminum[J]. Jounal of Materials Processing Technology, 2012, 212: 553-559.

DOI: 10.1016/j.jmatprotec.2011.05.022

[4] Lajczok M R. A Study of Some Aspect of Metal Cutting By the Finite Element Method[D]. NC Stats University. (1980).

[5] Fan Shutian, Wang Guicheng. Study on the Morphology of Feed-direction Burr in turning[J]. Journal of Jiangsu University of Sicence and Technology, 1999, 20: 57-60.

[6] Zhu Yunming, Wang guicheng, Fan Shutian, et al. A Study on Milling Burr Expert System in Micro-Machining[C]. 2008 International Conference on Intelligent Computation Technology and Automation.

DOI: 10.1109/icicta.2008.119

[7] Tugrul Ozel. Computational Modelling of 3D Turning: Influence of Edge Micro-geometry on Forces, Stresses, Friction and Tool Wear in PcBN Tooling[J]. Journal of Materials Processing Technology, 2009, 209: 5167-5177.

DOI: 10.1016/j.jmatprotec.2009.03.002

[8] Kiha Lee, David A Dornfeld. Micro-burr formation and minimization through process control[J]. Precision Engineering, 2005, 29: 246- 252.

DOI: 10.1016/j.precisioneng.2004.09.002
