The Design of Inertial Tracking System Based upon MEMS Sensor

Abstract:

Heading tracking technology is applied in many fields such as helm aiming, Virtual Reality etc. In this paper, one kind of orientation tracking system based upon MEMS accelerometer and magnetometer is designed. MCU can get the input data from the sensors through data bus, and upload the data to PC. The corresponding program is designed with Visual C++ to receive data and draw the 3D location in real time. The PC will adjust the attitude angle through Kalman filter. The experiment result show that the system is on operation well, and can be developed more function based upon it.

• Periodical: Applied Mechanics and Materials (Volume 590)
• Pages: 432-436
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.590.432
• Online since: June 2014
• Authors: Kai Liu, Kun Qian, Hua Che
• Keywords: Heading Tracking, Kalman Filter, MEMS Sensor, Micro-Chip

References

[1] Wang Chong, Shi Yuxia, Lu Xiong, Human Motion Measuring Equipment Based on Acceleration Sensor [J]. Microcontrollers ＆ Embedded Systems, (2011).

[2] Qing Yongyuan. The Principle of Kalman filter and Integration Navigation [M]. (2008).

[3] Markley F L. Attitude error representations for Kalman filtering [J]. Journal of Guidance, Control, and Dynamics, (2003).

[4] Murrell W. Precision attitude determination for multi-mission spacecraft[C]/ AIAA Guidance and Control Conference. New York: American Institute of Aeronautics and Astronautics, (1978).
