Experimental Analysis of a 20° Twist Helical Savonius Rotor at Different Overlap Conditions

Abstract:

Wind power is a major source of sustainable energy and can be harvested using both horizontal and vertical axis wind turbines. Vertical axis wind turbines (VAWTs) accrue more popularity due to its self-starting characteristics and Omni directional in nature. Out of which Savonius rotor is the most popular drag-based VAWT which is having lower efficiencies but having good self-starting characteristics. In order to improve the performance, helix in the tip of the blade is targeted which reduces the negative torque coefficient of the rotor thereby could improve the performance of the rotor. Therefore, in this paper the power coefficients of a two-bucket helical Savonius rotor at different overlap ratios (from 0.0% to 19.76%) with helix twist angle of 20° are investigated experimentally. The investigations mainly concentrate to find out the optimum overlap ratio which is responsible for generation of maximum aerodynamic power. It is seen from the results that the power coefficient of the rotor increases with the increase in overlap ratio up to a certain limit, and further increase of the same decreases the power coefficients. The maximum power coefficient C_p of 0.289 is obtained at an optimum overlap ratio of 12.76 %.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 1060-1064
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.1060
• Online since: July 2014
• Authors: Bachu Deb*, Rajat Gupta, R. D. Misra
• Keywords: Helical Savonius Rotor, Overlap Ratio, Power Coefficient, Tip Speed Ratio

References

[1] Fujisawa N. On the torque mechanism of Savonius rotors. Journal of Wind Engineering and Industrial Aerodynamics 1992; 40: 277–292.

DOI: 10.1016/0167-6105(92)90380-s

[2] Fujisawa N, Gotoh F. Pressure measurements and flow visualization study of a Savonius rotor. Journal of Wind Engineering and Industrial Aerodynamics 1992; 39: 51-60.

DOI: 10.1016/0167-6105(92)90532-f

[3] Fujisawa N, Gotoh F. Experimental Study on the Aerodynamics performance of a Savonius rotors. Journal of Solar Energy Engineering, Transactions of the ASME 1994; 116: 148-152.

DOI: 10.1115/1.2930074

[4] Saha UK, Jaya Rajkumar M. On the performance analysis of Savonius rotor with a twisted blades. Renewable Energy 2006; 31: 1776-1788.

DOI: 10.1016/j.renene.2005.08.030

[5] Kamoji MA, Kedare SB, Prabhu SV. Performance tests on helical Savonius helical Savonius rotors. Renewable Energy 2009; 34: 521-529.

DOI: 10.1016/j.renene.2008.06.002

[6] Damak A, Driss Z, Abid MS, Experimental Investigation of helical Savonius rotor with a twist of 180°. Renewable Energy 2013; 52: 136-142.

DOI: 10.1016/j.renene.2012.10.043

[7] Bhaumik. T, Gupta.R., Performance measurement of a two bladed helical Savonius rotor". Proceedings of the 37th International & 4th National Conference on Fluid Mechanics and Fluid Power FMFP2010 December 16-18, 2010, IIT Madras, Chennai, India.

[8] Gupta. R and Deb. B., CFD analysis of a two-bucket helical Savonius rotor with shaft at 45° twist angle. Sharjah International Symposium of Nuclear and Renewable Energies for 21st Century (SHJ-NRE11), April 3-5, 2011, College of Sciences, University of Sharjah UAE.

DOI: 10.5539/mer.v3n1p118

[9] Gupta R, Deb B & Misra R.D., Performance Analysis of a Helical Savonius Rotor with Shaft at 45° Twist Angle Using CFD. Journal of Mechanical Engineering Research, vol. 3, (2013).

DOI: 10.5539/mer.v3n1p118

[10] Deb B, Gupta R, & Misra R.D. Experimental Analysis of a 10° Helical Savonius Rotor at different overlap conditions,. Energy system modeling and optimization conference (ESMOC 2013), December 9-11, 2013 at National Institute of Technology-Durgapur.

[11] Mahmoud, N.H., El-Haroun, A.A., Wahba, E., Nasef, M.H., An Experimental Study on Improvement of Savonius rotor Performance. Alexandria Engineering Journal, (2012).

DOI: 10.1016/j.aej.2012.07.003
