Three Dimensional FE Modeling of the Scratch Test for DLC Coated High Speed Steel Substrate

Abstract:

Diamond-like-carbon (DLC) coatings provide excellent surface properties on substrate. With novel advanced techniques like modeling and simulation, the performance of these coatings can be predicted under different loading condition. Aim of present study was to developed three dimensional models for calculating first principal stress distribution components in the scratch test contact as the spherical diamond tip is moving with increasing load on a DLC Coated high speed steel substrate. Two different types of coatings (DLC 2, DLC 6) were used and find out the stress distribution on coatings and substrate. The models were developed in HYPERMESH and analyzed in RADIOSS software. The model is comprehensive in the sense that it considers elastic, plastic and fracture behavior of the coating surfaces.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 1235-1239
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.1235
• Online since: July 2014
• Authors: Pravin S. Pandure*, Vijaykumar S. Jatti, T.P. Singh
• Keywords: Diamond like Carbon Coating, First Principal Stress, HyperMesh, Radioss

References

[1] J. Li, W. Beres, Three-dimensional finite element modelling of the scratch test for TiN coated titanium alloy substrate, Wear 260 (2006) 1232-1242.

DOI: 10.1016/j.wear.2005.08.008

[2] K. Holmberg, A. Laukkanen, H. Ronkainen, K. Wallin, S. Varjus, J. Koskinen, Tribological contact analysis of a rigid ball sliding on a hard coated surface Part I: Modelling stresses and strains, Surface & Coatings Technol. 200 (2006) 3793-3809.

DOI: 10.1016/j.surfcoat.2005.03.040

[3] K. Holmberg, A. Laukkanen, H. Ronkainen, K. Wallin, S. Varjus, J. Koskinen, Tribological contact analysis of a rigid ball sliding on a hard coated surface Part II: Material deformations, influence of coating thickness and Young's modulus, Surface & Coatings Technol. 200 (2006).

DOI: 10.1016/j.surfcoat.2005.03.041

[4] K. Holmberg, H. Ronkainen, A. Laukkanen, K. Wallin, Friction and wear of coated surfaces- scales, modelling and simulation of tribomechanisms, Surface & Coatings Technol. 202 (2007) 1034-1049.

DOI: 10.1016/j.surfcoat.2007.07.105

[5] M. Lichinchi, C. Lenardi, J. Haupt, R. Vitali, Simulation of Berkovich nanoindentation experiments on thin films using finite element method, Thin Solid Films 333 (1998) 278-286.

DOI: 10.1016/s0040-6090(97)00739-6

[6] D.E. Vlachos, Y.P. Markopoulos, V. Kostopoulos, 3-D Modeling of nanoindentation experiment on a coating-substrate system, Contact Mechanics 27(2) (2001) 138-144.

DOI: 10.1007/s004660000222
