Experimental Investigation and Performance Evaluation of a Multi Turn Closed Loop Pulsating Heat Pipe

Abstract:

Pulsating heat pipe (PHP) is a passive heat transfer device, which transfers heat from one region to another with exceptional heat transfer capacity. It utilizes the latent heat of vaporization of the working fluid as well as the sensible heat. As a result, the effective thermal conductivity is higher than that of the conductors. An experimental study on three turn closed loop pulsating heat pipe with three different working fluids viz., Acetone, Methanol, Heptane and distilled water were employed. The PHP is made up of brass material with an inner diameter of 1.95mm, with a total length of 1150 mm for different fill ratios (FR) was employed .The PHP is tested for the thermal resistance and the heat transfer coefficient. The experimental result strongly demonstrates that acetone is a better working fluid among the working fluids considered in terms of higher heat transfer coefficient and lower thermal resistance.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 1554-1558
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.1554
• Online since: July 2014
• Authors: N. Narendra Babu*, Rudra Naik
• Keywords: Fill Ratio, Heat Input, Heat Transfer Coefficient, Thermal Resistance

References

[1] Lue N K, Sakulchangsatjatai P and Terdtoon P. Horizontal closed- loop pulsating Heat Pipe with multiple heat sources, 16th International Heat Pipe Conference (6th IHPC) Lyon, France, May 20-24, (2012).

DOI: 10.1080/01457632.2013.870000

[2] Haizhen Xian., Yongping Yang., Dengying Liu., Xiaoze Du., Heat transfer characteristics of pulsating Heat Pipes with water and ethanol as working fluids, Journal of Heat Transfer, Vol. 132, Dec 2010, pp.121501-05.

DOI: 10.1115/1.4002366

[3] Rittidech, S., Nimkin, S, Effect of Working Fluids and Evaporator Temperatures on Internal Flow Patterns and Heat Transfer Rates of a Top Heat Mode Closed Loop Oscillating Heat Pipe with Check Valves, Australian Journal of Basic and Applied Sciences, Vol. 5(10), 2011, pp.1013-1019.

DOI: 10.1080/08916152.2011.559568

[4] Yang, H., Khandekar, S., Groll, M., Operational limit of closed loop pulsating Heat Pipes, Applied Thermal Engineering, Vol. 28, 2008, p.49 – 59.

DOI: 10.1016/j.applthermaleng.2007.01.033

[5] Khandekar, S., Thermo Hydrodynamics of Pulsating Heat Pipes, PhD Dissertation, University of Stuttgart, Germany, (2004).

[6] Faghri A: Heat pipe science and technology, by Taylor & Francis (1995).

[7] Reay D, Kew P: Heat Pipes theory, Design and Applications, Fifth edition (2006).

[8] Khandekar, S., Pulsating Heat Pipes: Thermo-fluidic Characteristics and Comparative Study with Single Phase Thermosyphon, Proceedings of 12th International Heat Transfer Conference, Vol. 4, pp.459-464, Grenoble, France, (2002).

DOI: 10.1615/ihtc12.2720

[9] Mameli M., Marengo M., Zina S., Numerical Model of a Multi-turn Closed Loop Pulsating Heat Pipe: Effect of the Local Pressure losses due to Meanderings, Int. Journal of Mass and Heat Transfer Vol. 55, 2012, pp.1036-1047.

DOI: 10.1016/j.ijheatmasstransfer.2011.10.006

[10] Khandekar. S. Gupta. A., Embedded Pulsating Heat Pipes Radiators, 14th International Heat Pipe Conference (14th IHPC), Florianópolis, Brazil, April 22-27, (2007).

[11] Aboutalebi, M., A. M. Nikravan Moghaddam and M. B. Shafii. The effect of filling ratio on the performance of a rotating pulsating Heat Pipe, 16th International Heat Pipe Conference (16th IHPC) Lyon, France, May 20-24, (2012).

DOI: 10.1016/j.icheatmasstransfer.2013.04.008

[12] Mauro Mameli, Sameer Khandekar and Marco Marengo, Exploratory study of a Pulsating Heat Pipe operated with a two component fluid mixture, Proc. of the 21st National and 10th ISHMT-ASME Heat and Mass Transfer Conference, Dec 27-30, 2011, IIT Madras, India.
