Thermal Analysis of Ceramic Coated Aluminium Piston with Slots

Abstract:

The main aim is to control thermal expansion in aluminium piston at high working condition. A plasma sprayed ceramic coating (TBC) is applied on the piston crown as a top coat and NiCrAl is applied as the middle layer as bond coat to improve the addition strength between the top coat and the metal subtract layer as AlSi alloy; we introduce a thermal slot on the piston shrink to regulate the heat flow in piston and make it cooler. We analyse the piston with these two implementations to determine the thermal analysis of the piston. The results can be shown in the various comparisons of coating thickness of top coat with thermal slots on the piston shrink. Increase in coating thickness reduces the stress in the coatings. It is observed that 85°C increase in 0.8mm coat than the ordinary piston.

• Periodical: Applied Mechanics and Materials (Volumes 592-594)
• Pages: 786-790
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.592-594.786
• Online since: July 2014
• Authors: M.R. Chitthaarth*, K. Manivannan
• Keywords: Aluminium Piston, Ceramic Coating, Thermal Analysis, Thermal Slots

References

[1] X.Q. Cao., R. Vassen., D. Stoever., Ceramic materials for thermal barrier coatings, Journal of the European Ceramic Society 24 (2004) 1–10.

DOI: 10.1016/s0955-2219(03)00129-8

[2] Chittharth .M.R., Charles dhony naveen .I.A., Sunilkumar .G., Dr. K. Manivannan, Design and Analysis of new Type slots on Piston to control Thermal Expansion, International journal of applied engineering research, volume 8, number 7 (2013).

[3] Ekrem Buyukkaya., Muhammet Cerit., Thermal analysis of a ceramic coating diesel engine piston using 3-D finite element method, Surface & Coatings Technology 202 (2007) 398–402.

DOI: 10.1016/j.surfcoat.2007.06.006

[4] Ekrem Buyukkaya., Thermal analysis of functionally graded coating AlSi alloy and steel pistons, Surface & Coatings Technology 202 (2008) 3856-3865.

DOI: 10.1016/j.surfcoat.2008.01.034

[5] T. Hejwowski., A. Weronski., The effect of the thermal barrier coating on diesel engine performance, vacuum 65, surface instrumentation vacuum technology (2002) 427-432.

DOI: 10.1016/s0042-207x(01)00452-3

[6] Muhammet Cerit., Thermo mechanical analysis of a partially ceramic coated piston used in an SI engine, Surface & Coatings Technology 205 (2011) 3499–3505.

DOI: 10.1016/j.surfcoat.2010.12.019

[7] Muhammet Cerit., Mehmet Coban., Temperature and thermal stress analyses of a ceramic-coated aluminum alloy piston used in a diesel engine, International Journal of Thermal Sciences 77 (2014) 11-18.

DOI: 10.1016/j.ijthermalsci.2013.10.009

[8] K. Sridhar., R. Reji Kumar., M. Narasimha., Thermal barrier Analysis in Diesel, International Journal of Modern Engineering Research, Vol. 3, Issue. 3, May-June. (2013) pp-1435-1441.
