Simulation and Design of Portable Underwater Acoustic Transducer Test Device

Abstract:

In this paper, a portable underwater acoustic transducer sensitivity test device is designed to overcome the disadvantages of traditional test methods, such as the bigger size of anechoic pool, and single function of the vibrating column of liquid method. This new design has the advantage of small size, easy to carry and implement. A model of this device is constructed based on the finite element analyse software COMSOL Multiphysics. By calculating the sound field distribution of the test device model, the optimization size of the piezoelectric ceramic can be determined. Also the effect of some other key parameters, such as the material of vessel and thickness, are considered. All these results can provide the theoretical basement of the design of portable underwater acoustic transducer in practice.

• Periodical: Applied Mechanics and Materials (Volumes 599-601)
• Pages: 445-450
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.599-601.445
• Online since: August 2014
• Authors: Tao Wei Huang*, Di Xiang Chen, Cheng Guang Fan
• Keywords: Model, Piezoelectric Ceramic (PZT), Sensitivity, Underwater Acoustic Transducer

References

[1] J Robbert. Underwarter Electroacoustic Measurement Naval Research Laboratory．Washiongton, D.C., 1970, 273-283.

[2] G G Dieslel. Reciprocity calibration of microphones in a diffuse sound field．J Acoust Soc Am，33(1961): 514.

[3] F. Schloss and M. trasberg. Hydrophone Calibration in a Vibration Column of Liquid J.A.S.A. 34(1962): 958-960.

[4] B Benjamin. Bauer, A Louis. Abbagnaro and Juergen Schumann. Wide-Range Calibration System for Pressure-Gradient Hydrophone J.A.S.A. 51(1972): 1717-1724.

DOI: 10.1121/1.1913019

[5] S. M Peelamedu., N Naganathan. and S Buckley. Impact analysis of automotive structures with distributed smart material systems. In Proceedings of the Sixth SPIE Conference on Smart Materials and Structures , Proceedings of the SPIE. 3667(1999).

DOI: 10.1117/12.350138

[6] S. M Peelamedu, N Naganathan, D Leo and R Dukkipati. Energy absorption using smart materials during impact. In Proceedings of the Fifth National Applied Mechanisms and Robotics Conference, Publication AMR97-055, 2(1997): 1-8.

[7] HUANG Yihua，ZHOU Kangyuan, CHEN Xin, eta1. The development of piezoelectric transformer—reviewand expectation[J]. TechnicalAcoustics, , 2l(2002): 122-127.

[8] Hu Y T, Zhang X S, Yang J S, Jiang Q. Transmitting electric energy through a metal wall by acoustic using piezoelectric transducers. [J] IEEE Transactions on Ultrasonics, 50(2003): 773-781.

DOI: 10.1109/tuffc.2003.1214497

[9] Hu H P, Hu Y T, Chen C Y, Wang J. A system of two piezoelectric transducers and a storage circuit for wareless energy transmission through a thin metal wall. [J] IEEE Transactions on Ultrasonics, Ferroeletrics, and Frequency Control, 55(2008).

DOI: 10.1109/tuffc.930
