Research on One Kind of Intellectualization High Accuracy Digital Adjustment Direct Source

Abstract:

The power source uses the digital adjustment, the closed loop real-time monitoring.The output precision is vary high. It also has both the dual over-load protection and alarm, which is suitable especially in each kind situation of the high accuracy request.This design intellectualization direct-current power supply uses the self-restraint keyboard entry. The system of intellectualization high accuracy digital adjustmen direct source contains D/A module and A/D module . D/A module adopts low-priced 8 bits DA chip. DAC0832 is a electric current exports type 8 bits D/A converter , adopting to reversing T type resistor network. The ADC0809 chip,with 8 bits AD changes ,accomplishes the data collect function and makes up into the closed cycle circuit. The inside of ADC0809 has output lock-memory implement , it can link up with AT89C51 monolithic machine directly. The stabilivolt outputed and over-stream protection module adopts the in-line stabilivolt circuit which has used three end integrated stabilivolt chip , adopting LM317 and LM337 series three hold adjustable stabilivolt tube., LM317 is a three end adjustable voltage stabilizer integrated circuit of USA country semiconductor company.The single-chip microcomputer receives voltage value information of keyboard input, and carries on processing.

You might also be interested in these eBooks

Frontiers of Manufacturing Science and Measuring Technology IV

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 599-601)

Pages:

608-611

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.599-601.608

Citation:

Cite this paper

Online since:

August 2014

Authors:

Yan Hui Xu*, Dan Tong Zhang

Keywords:

Direct Source, High Accuracy, Single-Chip Microcomputer
