Design of a 10MPa Nanosecond Gas Switch with Adjustable Gap

Abstract:

This paper introduces a method to adjust the gap distance of nanosecond gas switch from outside when it is filled with high pressure gas. By using a two-stage planetary gear train and a pinion-and-rack device the gap between the electrodes can be linearly adjusted. The adjusting precision is 0.05 mm and adjustment range is 0 to 10 mm. The sealing of the insulator ring, rotation axle and outside conductors is designed. The performance of the rotation axle is pretty well under 12MPa gas pressure, air leakage not found. Experimental study on switch discharging is carried out by using a high voltage nanosecond pulse generator. The results show the output voltage of the pulse can reach 600kV by adjusting the switch gap. The rise-time of the pulse can be shortened form 3.5ns to 1ns.

• Periodical: Applied Mechanics and Materials (Volumes 599-601)
• Pages: 643-647
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.599-601.643
• Online since: August 2014
• Authors: Bao Feng Cao*, Jiang Bing Fan, Li Jun Song, Xin Li, Peng Li, Hong Wei Zhao, Qiu Han Liu, Wang Shi Ning
• Keywords: Gap Adjustable Switch, Gas Sealing, Gas Switch, Nanosecond Pulse, Ultra-Wideband

References

[1] Sun Xu, Su Jiancang, Zhang Xibo, et al. Resistance properties of gas spark switch. High Power Laser and Particle Beams, 2012, 24(04): 843-846.

DOI: 10.3788/hplpb20122404.0843

[2] Wu Hanyu, Zhang Xinjun, Wang Liangping, et al. Structural design of 2 MV laser triggered multi-stage gas switch. High Power Laser and Particle Beams, 2012, 24(03): 630-634.

DOI: 10.3788/hplpb20122403.0630

[3] He Wei, Li Li, Zheng Wanguo, et al. 500 kA switch-trigger system for 2. 0 MJ capacitive pulsed power supply. High Power Laser and Particle Beams, 2013, 25(05): 1293-1297.

DOI: 10.3788/hplpb20132505.1293

[4] Agee F J, Baum C E, Prather W D, et al. Ultra-wideband transmitter research. IEEE Trans Plasma Science, 1998, 26(3): 861.

[5] Cong Peitian, Qiu Aici, Sun Tieping, et al. Discharge process and closure jitter of six-stage gas switch under pulsed trigger. High Power Laser and Particle Beams, 2013, 25(05): 1303-1306.

DOI: 10.3788/hplpb20132505.1303

[6] Luo Weixi, Huang Tao, Zeng Jiangtao. Influence of gap length on gas spark switch static performance. High Power Laser and Particle Beams, 2013, 25(09): 2466-2470.

DOI: 10.3788/hplpb20132509.2466

[7] Shi Lei, Fan Yajun, Zhu Sitao, et al. Experimental study on discharge characteristics of a sub-nanosecond high pressure N2 switch, High Power Laser and Particle Beams, 2005，17(7)：1079-1082.

[8] Fan Yajun, Shi Lei, Liu Guozhi, et al. Generation of high power ultra wideband bipolar pulse with chopping-peaking switch. High Power Laser and Particle Beams, 2004, 16(4): 501-504.

[9] Zhang Xianfui, Lu Wei, Chen Zhigang, et al. Development of sub-nanosecond gas switch with adjustable gap, High Power Laser and Particle Beams, 2008，20(4)：697-700.

[10] Zhang Xianfui, Lu Wei, Chen Zhigang, et al. Optimizing design of sub-nanosecond gas switch with adjustable gap, High Power Laser and Particle Beams, 2009，21(9)：1380-1384.

[11] Wang Qilong, Ruan Zhongtang, Jiang Changye. et al. Mechanical engineering handbook (version 2), volume of driving motion design, Beijing: Mechanical Engineering Press, (2001).

[12] Cao Baofeng, Song Lijun, Li Peng. Measuring HNEMP with capacitive voltage divider. Journal of chemical defense, 2008(2): 41-43.

[13] Ding Desheng, Yi Lingzhi, Yu Binxiong, et al. Capacitive divider for output voltage measurement of intense electron beam accelerator. High Power Laser and Particle Beams, 2012, 24(10): 2497-2501.

DOI: 10.3788/hplpb20122410.2497
