Simulation Research on Optical Performance of Multicrystalline Silicon Texture Structure

Abstract:

The finite element model of double etching pits was established, optical performance of multicrystalline silicon wafer before and after etching was simulated by RF MODULE of COMSOL Multiphysics version 3.5a. Optical characteristic of unetching wafer and acidic textured were compared. It is indicates that acidic textured (double etching pits) has low reflectivity, high power flow Y component , the better light trapping. When the wavelength is 600nm, the maximum and minimum value of surface electric field Z component of acidic textured are 1.9 times and 1.4 times respectively than that of unetching wafer, and two extremum value of surface magnetic field Z component are 2.1 times and 1.9 times respectively than that of unetching wafer. Numerical simulation results of Multi hole model are closely with experimental values, which can guide the practical production.

• Periodical: Applied Mechanics and Materials (Volumes 599-601)
• Pages: 99-102
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.599-601.99
• Online since: August 2014
• Authors: Fa Yun Zhang*
• Keywords: Double Etching Pits, Multicrystalline Silicon, Numerical Simulation, Reflectivity, Texturing

References

[1] Y. Chao, L.Q. Wu, W. Fan, et al, A Study of Texturing on the Surface of Advanced Multi-Crystalline Silicon Solar Cell, Advanced Science Letters. 19 (2013)3301-3303.

DOI: 10.1166/asl.2013.5148

[2] J. Yoo, J.S. Cho, S.J. Ahn, et al, Random reactive ion etching texturing techniques for application of multicrystalline silicon solar cells, Thin Solid Films. 546(2013)275-278.

DOI: 10.1016/j.tsf.2013.02.045

[3] S. W. Park，J. Kim, Application of Acid Texturing to Multi-Crystalline Silicon Wafers. Journal of the Korean Physical Society, Journal of the Korean Physical Society. 43(2003)423-426.

[4] Y. Qian, S. Feng, Effect of Multi-Crystalline Silicon pit-trap shape on the optical reflectance, Ａcta Optica Sinica. 32(2012)1-6.

[5] F. Hamid, W. Zhou, H. Zheng, et al, Numerical Simulation of Non-Ablative Laser Texturing of Silicon Surface with a Continuous Wave Fiber Laser, Journal of Computational and Theoretical Nanoscience. 11(2014)53-57.

DOI: 10.1166/jctn.2014.3316

[6] F.Y. Zhang, A simulation study on optical properties of trap pits morphology of multicrystalline silicon, Acta Photonica Sinica. 41(2012), 1076-1080.

DOI: 10.3788/gzxb20124109.1076

[7] F.Y. Zhang, Simulation study on optical properties of acidic texturing of multicrystalline silicon, Journal of solar energy. 33(2012), 1366-1370.
