A Design and Research on GMM Precision Flow Pump

Abstract:

A new type of the precision flow pump is developed with the giant magnetostrictive materials as the driving source. Experiment has been conducted to test the performance of the pump with designed key components. The pump as the preloading mechanism, adopting an elastomer instead of a spring, not only simplifies the structure, but also improves the performance of the pump. A design is also made to some key components such as the giant magnetostrictive rod and driving coil. The result of experiment shows that the pump flow resolution records 1 ml/min~400ml/min and the maximum output pressure 0.6 MPa, which means the performance of this kind of pump is superior to ordinary diaphragm pumps.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 117-121
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.117
• Online since: August 2014
• Authors: De Hui Liu*, Li Wen Liu, Gang Tang, Hong Min Wen, Quan Guo Lu
• Keywords: Flow Pump, Giant Magnetostrictive Materials, Precison Control

References

[1] Bowen Wang, The preparation and device design of giant magnetostrictive material, Metallurgical industry press, 2003. 8.

[2] Chengying Li etc, The research and application development of the rare earth giant magnetostrictive materials in China, The journal of Liaoning Institute of Technology, 1999: 19(3): 14~20.

[3] Hiroyudi fujita. A decade of MEMS and its future [D]. in Proc. of the IEEE Micro Electro Mechanical Sys-tems, 1997: 1-8.

[4] Krulevitch P. Thin film shape memory alloy micro actuators [J]. Journal of Micro Electro Mechanical Systems, 1996, 5(4): 270-281.

[5] Wang Tian-Zhong, he Zhou-You. A theoretical study of non-linear effect in magnetostrictive-piezoelectric trilayer[J]. Composite Structures, 2011(93): 1485-1492.

DOI: 10.1016/j.compstruct.2010.12.003
