Optimization Design of Lifting Beam for Heavy Engine Compartment Based on Ansys Workbench

Abstract:

The mechanical analysis of the lifting beam for heavy engine compartment was analyzed by traditional theoretical mechanics and material mechanics methods, and the basic structural shape of the lifting beam was design. The FEM intensity analysis, strength check and the structural optimization design of the lifting beam were carried out by making use of the software of ANSYS Workbench, and the reasonable structural shape and size of the section were got. Through optimization design, the material was saved, the weight of the lifting beam was lessened, and the economic benefit was improved.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 234-238
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.234
• Online since: August 2014
• Authors: Bao Jun Wang*, Yi Tao, Jiang Wei Li, Rui Chao Chang, Lei Qiang Zong
• Keywords: ANSYS Workbench , Lifting Beam, Mechanical Analysis

References

[1] Liu Bin, Chu Wenjun. Design of 50T Lifting Beam with I-Sharped Section [J], Steel Construction, 2008, 23(10) 35-39.

[2] Xu Yuhua, Liu Hengchun, Zheng Jianguo. Check Analysis of the Strength of A Type of General-use Lift Beam [J]. Logistics Technology, 2013, 30(11) 88-91.

[3] Cha Taidong, Yang Ping. Optimization Design of Fixed Support Based on Ansys Workbench [J], Coal Mine Machinery, 2012, 33(2) 28-30.

[4] Li Yaping, Zhong Peisi, Gong Wenfeng. Modal Analysis of Picking Chip Head Based on Anasys Workbench [J]. Hydro Mechatronics Engineering, 2013, 41(12) 83-88.

[5] R C Hibbeler. Mechanics of Materials [M]. High Education Press, (2014).
