Leakage and Dispersion Modeling of Hydrogen in the Docking Process of Docking Mechanism and Exhaust Pipe of Rocket Tank

Abstract:

This paper illustrates an application of the mass transport model, turbulent model and dynamic mesh technique to the simulation of hydrogen leakage and dispersion in the Docking Process of exhaust pipe of rocket tank. Some numerical simulations are made to investigate on the effects of the tank pressure, docking mechanism and buoyancy. The experiment results indicate that tank pressure has significant influence in horizontal direction and vertical direction of hydrogen diffusion. Besides, the effects of buoyancy are slight. In addition, direction of hydrogen flow has been changed to vertical direction mostly at 2ms as a result of the action of docking mechanism, and there are no longer dangerous concentration areas of hydrogen inside the exhaust pipe after 2ms of leakage.

• Periodical: Applied Mechanics and Materials (Volumes 602-605)
• Pages: 566-570
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.602-605.566
• Online since: August 2014
• Authors: Yuan Li*, Jing Peng Chen, Cun Yan Cui, Yun Chun Jiang, Xiao Yong Li, Xing Li
• Keywords: Docking Mechanism, Dynamic Mesh, Hydrogen, Leakage

References

[1] Koopman R P, Cederwall R T, Ermak D L, et al. Analysis of Burro series 40-m3 LNG spill experiments[J]. Journal of Hazardous Materials, 1982, 6(1): 43-83.

DOI: 10.1016/0304-3894(82)80034-4

[2] Goldwire H C, Morris L K, Kamppinen L, et al. Coyote series data report, LLNL/NWC, LNG spill tests[J]. Livermore, California: Lawrence Livermore National Laboratory, (1983).

[3] Taraldset O J. FLACS v9. 0 Manual[J]. GexCon R&D, (2009).

[4] Arthur D. Little Inc. Final report on an investigation of hazards associated with the storage and handling of liquid hydrogen[J]. Report C-61092, (1960).

[5] Witcofski R D. Dispersion of flammable clouds resulting from large spills of liquid hydrogen[C]. 1981: 284-208.

[6] Marinescu-Pasoi L, Sturm B. Messung der Ausbreitung einer Wasserstoff-und Propangaswolke in bebautem Gelände and Gasspezifische Ausbreitungsversuche[J]. Battelle Ingenieurtechnik GmbH, Reports R-68. 202 and R-68. 264, (1994).

[7] Statharas J C, Venetsanos A G, Bartzis J G, et al. Analysis of data from spilling experiments performed with liquid hydrogen[J]. Journal of hazardous materials, 2000, 77(1): 57-75.

DOI: 10.1016/s0304-3894(00)00252-1

[8] Proust C, Lacome J M, Jamois D, et al. Processes of the formation of large unconfined clouds following a massive spillage of liquid hydrogen on the ground[C]/Proceedings of 2nd International Conference of Hydrogen Safety, San Sebastian, Spain. 2007: 11-13.

[9] Zhang Shi-shuai. Computational fluid dynamics and its applications[M]. Huazhong University of Science and Technology press, (2011).

[10] Sui Hong-tao, Li Peng-fei. Proficient in CFD dynamic grid engineering simulation and practice case[M]. People's Posts and Telecommunications Press, (2013).
