Finite Element Analysis and Topology Optimization Design for Motional Board of Injection Molding Machine

Abstract:

The structure and the load-carrying capability of the front board of injection molding machine are more complex. The error of the approximation algorithm employed in engineering is larger so that the board may become invalid in the process of using, The finite element analysis can obtain the stress distribution in the parts so as to improve the accuracy of calculation and the quality of design; through The topology optimization analysis will take the initiative to find the optimal plan, which provides the theoretical basis for the improvement of the load-carrying capability and the structure design of board. This paper have conducted a parametric design, finite element analysis and the topology optimization design for a motional board of the injection molding machine using “Advanced simulation” of NX8.0, and get a quantitative conclusion of that the motional board volume is reduced and its stiffness is significantly enhanced.

• Periodical: Applied Mechanics and Materials (Volume 607)
• Pages: 573-576
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.607.573
• Online since: July 2014
• Authors: En Guang Zhang*, Li Wang, Wen Ju Shan
• Keywords: Board, Finite Element Analysis (FEA), Injection Molding Machine, Topology Optimization

References

[1] Ma Yushan, Jin Tao, Gong Jianguo et al. Stress and Fatigue Analysis and Optimization of Injection Molding Machine [J]. Plastics Industry, 2010, 38(9): 40-44.

[2] Beijing Institute of Chemical Technology, South China Institute of Technology. Plastic Machinery Design [M]. Beijing: China Light Industry Press, 1983: 434-449.

[3] Xu Ke. Finite Element Analysis and Design Optimization of Injection Molding Machine [D]. Beijing University of Chemical Technology, (2009).

[4] Zhang Shenglan, Zheng Dongli, Hao Qi et al. Structure Optimization Design Technology Based on HyperWorks [M]. Beijing : Mechanical Industry Press, 2007: 170-172.

[5] Xu Guangju, Zhu Shengjuan, Zhao Yixiang et al. Injection Molding Machine Structural Analysis and Dynamic Board Optimization Design Based on ANSYS. [J]. Electrical Engineering Technology. 2010, 39(3): 48-50.
